Phoenix Contact CDDC254PV50 PCB Connector
The CDDC 2,5/ 4-PV-5,0 is a high-quality direct connector featuring SKEDD plug-in technology, suitable for PCB applications. It offers a 4-position configuration with a 5 mm pitch, rated for 12 A current and 320 V rated voltage. The connector is made from durable PA housing with a self-locking flange and linear pin layout, ensuring vibration-resistant and flexible PCB positioning. Ideal for applications requiring compact, reliable, and vibration-proof connections, it supports crimping with compatible tools and is compliant with industry standards, making it suitable for diverse industrial environments.
Phoenix Contact CDDC254PV50 PCB Connector Specifications:
- Range of articles CDDC 2,5/..-PV
- Number of positions: 4
- Pitch: 5 mm
- Connection method: Crimp connection
- Maximum current: 12 A
- Rated voltage: 320 V (III/2)
- Housing material: PA, color: green (6021)
- Housing flammability rating: UL 94 VO
- Temperatures: -40°C to 70°C storage, -5°C to 100°C assembly, -55°C to 105°C operation
- Dimensions: Length 13 mm, Width 25.8 mm, Height approximately 13 mm
- Number of connections: 8
- Contact surface: Tin
- Locking: Self-locking flange
- Applicable standards: IEC 61984, IEC 60664-1, IEC 60512-13-2
- Approvals: cULus Recognized, VDE, IEC CB Scheme
- Environmental Resistance: IP20, cold and thermal stress resistance, glow wire flammability index 850
- Compatible crimp contacts available for wire sizes 26-12 AWG
Buy the Buy Phoenix Contact CDDC 2,5/ 4-PV-5,0 Part Number CDDC254PV50 Online
Order the Phoenix Contact PCB connector with SKEDD plug-in technology today for fast, vibration-proof, and reliable connections in industrial applications. This 4-position connector rated for 12 A and 320 V ensures safe, vibration-resistant PCB assembly. Its compact design, self-locking flange, and tin-plated contacts make it ideal for high-density applications. Available in a green PA housing, it supports crimping with approved tools. Buy now to enjoy quick delivery, strong compliance with standards, and durable performance for your manufacturing or maintenance needs.
Get Phoenix Contact CDDC 2,5/ 4-PV-5,0 today—built for reliable PCB connections with vibration resistance and high current capacity.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC254PV50?
You can click on the BUY or RFQ button to purchase CDDC254PV50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC254PV50?
You can download the CDDC254PV50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC254PV50?
Phoenix Contact
