Phoenix Contact CDDC256PV50 PCB Direct Connector
The CDDC 2.5/6-PV-5.0 is a cost-effective, high-density direct connector featuring SKEDD direct plug-in technology, suitable for PCB applications with a 5 mm pitch. This green housing connector supports up to 6 positions, rated for 12 A and 320 V, with flexible crimp connection terminals for conductor cross sections from 0.14 mm² to 2.5 mm². Its robust design ensures vibration resistance, easy hand insertion, and compatibility with both HAL and chemically tin-plated surfaces, making it ideal for various industrial automation and control systems.
Phoenix Contact CDDC256PV50 PCB Direct Connector Specifications:
- Number of positions: 6
- Pitch: 5 mm
- Rated current: 12 A
- Rated voltage (III/2): 320 V
- Conductor cross section: 0.14 mm² to 2.5 mm² (AWG 26-14)
- Housing color: Green
- Housing material: PA, flammability rating UL 94 VO
- Contact surface: Tin
- Mounting: SKEDD direct plug-in technology
- Degree of protection: IP20
- Ambient temperature (operation): -55°C to 105°C
- Climatic tests: IEC 60068-2-70, IEC 60068-2-14
- Wire connection method: Crimp
- Dimensions: Length approximately 7.00 mm (pin spacing), width and height as per product design
- Certifications: VDE, cULus recognized, IEC 61984 compliance
- Number of connectors: 12 (two levels, 12 connections, 12 potentials)
Buy the Buy Phoenix Contact CDDC 2.5/6-PV-5.0 Part Number CDDC256PV50 Online
Order the Phoenix Contact CDDC 2.5/6-PV-5.0 direct connector online today to enjoy quick installation and reliable electrical connection. This high-quality PCB connector with SKEDD technology offers six positions with a 5 mm pitch, rated for 12 A and 320 V, suitable for industrial automation, control systems, and wiring harnesses. Its vibration-resistant, easy-insertion design saves time and costs, ensuring high packing density and long-term durability. Get yours now for efficient, vibration-proof connections in demanding environments.
Buy Phoenix Contact CDDC 2.5/6-PV-5.0 now and experience unmatched reliability and performance in compact PCB connections.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC256PV50?
You can click on the BUY or RFQ button to purchase CDDC256PV50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC256PV50?
You can download the CDDC256PV50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC256PV50?
Phoenix Contact
