Phoenix Contact DFKMSTB2512STF508LR Feed-Through Connector
This feed-through connector features a 12-position screw connection with tension sleeve, rated for 12A and 320V. It has a pitch of 5.08mm, a green housing made of insulating PA, and tin-plated contacts for reliable connection. Designed for use in control panels and automation systems, it supports flexible wiring with cross sections up to 2.5mm². Its robust construction meets international standards, including UL 94 V-0 flammability and IEC durability tests, ensuring safety and durability in industrial environments.
Phoenix Contact DFKMSTB2512STF508LR Feed-Through Connector Specifications:
- Number of positions: 12
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V (III/2)
- Contact material: Copper alloy, tin-plated
- Housing color: Green (6021)
- Housing material: PA (Polyamide)
- Conductor cross section: 0.2 mm² to 2.5 mm² (solid and flexible)
- Temperature range: -40°C to 100°C (operation), -5°C to 70°C (storage/transport)
- Flammability rating: UL 94 V-0
- Compliance: WEEE/RoHS
- Approximate dimensions: Length 19.3mm, Width 85.93mm, Height 16.5mm
- Certifications: IEC 60999, UL, CSA
- Protection class: IP20 (finger safety)
- Pull-out strength: >10 N (for 0.2 mm² to 2.5 mm²) conductors
- Insulation: Polyamide, with appropriate creepage and clearance standards
Buy the Phoenix Contact Series DFKMSTB 12-Position Feed-Through Connector: DFKMSTB2512STF508LR
Enhance your control panel wiring with the Phoenix Contact 12-position feed-through connector. Featuring screw connection with tension sleeve for secure installs, rated for 12A and 320V, it offers a pitch of 5.08mm and tin-plated contacts for durability. Its robust PA housing is green, ensuring clear identification and safety. Suitable for flexible and solid conductors up to 2.5mm², this connector complies with IEC and UL standards, providing reliable, safe, and durable connections in automation and industrial control applications. Order online now for fast delivery and quality assurance.
Order your Phoenix Contact Series DFKMSTB 12-Position Feed-Through Connector today and give your industrial wiring projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy Phoenix Contact DFKMSTB2512STF508LR?
You can click on the BUY or RFQ button to purchase DFKMSTB2512STF508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFKMSTB2512STF508LR?
You can download the DFKMSTB2512STF508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFKMSTB2512STF508LR?
Phoenix Contact
