Phoenix Contact DFKMSTB2515STF508LR Feed-through connector
This feed-through connector offers reliable wiring for industrial automation, suited for high-current and voltage applications. It features 15 positions with a pitch of 5.08 mm, screw connection with tension sleeve, and tin-plated copper contacts for robust electrical performance. Its green housing is made of durable PA insulation material rated for temperatures up to 100°C, with various accessories like bridging and coding elements enhancing connection security. The connector complies with international standards for electrical safety and durability, making it suitable for complex industrial systems requiring secure, maintenance-friendly connections.
Phoenix Contact DFKMSTB2515STF508LR Feed-through connector Specifications:
- Number of positions: 15
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V (III/2)
- Conductor cross section: 0.2-2.5 mm² (solid and flexible)
- Housing material: PA, color: green
- Contact surface: Tin-plated Cu alloy
- Temperature rating: -40°C to 100°C
- Flammability rating: UL 94 V-0
- Insulation material: PA
- Soldering/ mounting: Wave soldering for headers, screw connection for terminals
- Environmental tests: IP20, certified for IEC standards
- Dimensions: Length 19.3 mm, Width 101.17 mm, Height 16.5 mm, Pitch 5.08 mm
- Cable connection: Screw terminal, tension sleeve, push-in spring options available
- Compliance: RoHS, REACH, IEC standards
Buy the Phoenix Contact DFK-MSTB 2,5/15-STF-5,08-LR – Reliable Feed-Through for Industrial Applications
Proceed with your wiring projects confidently by purchasing the Phoenix Contact feed-through connector online today. Designed for durability and ease of installation, this connector supports 15 positions with a 5.08 mm pitch, rated for 12 A and 320 V. Its robust tin-plated contacts and high-quality PA housing ensure safe operation in demanding environments. Compatible with various accessories, it simplifies complex wiring tasks. Order now to ensure your automation systems are protected and efficient with a trusted industrial connector.
Buy Phoenix Contact DFK-MSTB 2,5/15-STF-5,08-LR now and experience unmatched reliability and performance in your industrial wiring solutions.
Frequently Asked Questions
Where can I buy Phoenix Contact DFKMSTB2515STF508LR?
You can click on the BUY or RFQ button to purchase DFKMSTB2515STF508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFKMSTB2515STF508LR?
You can download the DFKMSTB2515STF508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFKMSTB2515STF508LR?
Phoenix Contact
