Phoenix Contact DFKMSTB254GF508 Terminal Block Strip
The PHOENIX CONTACT DFK-MSTB 2 5/ 4-GF-5 08 terminal block strip is a versatile component for connecting wires and cables in electrical systems. Designed with a 5.08mm pitch and 4 positions, it offers a secure and reliable connection method through solder or slip-on connections. This strip is ideal for applications requiring direct mounting in housing panels up to 6mm thick, providing a robust and organized wiring solution. Its green color and tin-plated contact surface ensure durability and efficient signal transmission. The strip is compatible with MSTB 2.5 or FKC 2.5 plugs, offering flexibility in system design and integration.
Phoenix Contact DFKMSTB254GF508 Terminal Block Strip Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 320 V
- Number of positions: 4
- Pitch: 5.08 mm
- Connection method: Solder/Slip-on connection
- Color: green
- Contact surface: Tin
- Mounting: Direct mounting
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 5.65 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Dimension a: 15.24 mm
- Range of articles: DFK-MSTB 2,5/..-GF
- Insulating material group: I
- Rated surge voltage (III/3): 4 kV
- Rated surge voltage (III/2): 4 kV
- Rated surge voltage (II/2): 4 kV
- Rated voltage (III/3): 320 V
- Rated voltage (II/2): 630 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Insulating material: PA
- Flammability rating according to UL 94: V2
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27141134
- eCl@ss 9.0: 27141134
- ETIM 3.0: EC001283
- ETIM 4.0: EC001283
- ETIM 5.0: EC001283
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
