Phoenix Contact DFMC153ST35 PCB connector
The DFMC 1.5/ 3-ST-3.5 is a printed-circuit board connector featuring a 3-position design with 6 contacts, ideal for efficient wiring in control panels. It offers a push-in spring connection method, allowing quick, tool-free wiring while ensuring stable contact force for long-term reliability. Its compact dimensions—22.65 mm in length, 13.25 mm in height, and 11.3 mm in width—facilitate installation in tight spaces. Made from flame-retardant PA material, it supports rated voltages up to 160 V and nominal currents of 8 A, suitable for various industrial automation applications.
Phoenix Contact DFMC153ST35 PCB connector Specifications:
- Number of positions: 3
- Connection method: Push-in spring connection
- Rated voltage (III/2): 160 V
- Nominal current: 8 A
- Connection in accordance with EN-VDE standard
- Insulating material: PA (Polyamide)
- Flammability rating: UL 94 V-0
- Dimensions: Length 22.65 mm, Height 13.25 mm, Width 11.3 mm
- Pitch: 3.5 mm, Contact surface: Tin
- Stripping length: 10 mm
- Wire Cross-Section: Solid 0.2–1.5 mm², Flexible 0.2–1.5 mm², AWG 24–16
- Maximum load current: 8 A
- Rated surge voltage: 2.5 kV
- Standard compliance: EN-VDE, UL 94 V-0 flammability
- Environmental compliance: China RoHS, EFUP unlimited
Buy the Buy Phoenix Contact PCB Connector Part Number DFMC153ST35 Online
Enhance your electronic assemblies with the Phoenix Contact PCB connector, featuring 3 positions, quick push-in connection, rated for 8 A at 160 V, designed for reliable wiring in automation and control applications. Its compact size allows for seamless integration into tight spaces, ensuring stable contact over long-term use. Made from flame-retardant PA material and compliant with UL 94 V-0 standards, it provides safety, durability, and ease of installation, making it the ideal choice for industrial wiring and automation projects. Purchase online today for quick delivery and quality assurance.
Get Phoenix Contact DFMC 1.5/3-ST-3.5 today—reliable, space-saving PCB connector for efficient wiring in automation systems.
Frequently Asked Questions
Where can I buy Phoenix Contact DFMC153ST35?
You can click on the BUY or RFQ button to purchase DFMC153ST35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFMC153ST35?
You can download the DFMC153ST35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFMC153ST35?
Phoenix Contact
