Phoenix Contact FKC254STF508 PCB Connector
The FKC 2,5/ 4-STF-5,08 is a printed-circuit board connector designed for reliable and easy connections in electronic assemblies. It features a push-in spring connection for tool-free, quick installation, and a contact surface made of tin for optimal conductivity. With a pitch of 5.08 mm and rated for 12 A current and 320 V voltage, it ensures high performance with mechanical stability. Suitable for various PCB applications, this green-colored connector complies with UL 94 V-0 flammability ratings and standard EN-VDE. Its robust design supports efficient testing and secure connections in complex electronic systems.
Phoenix Contact FKC254STF508 PCB Connector Specifications:
- Range of articles: FKC 2,5/.-STF
- Number of positions: 4
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V (III/2)
- Connection method: Push-in spring connection
- Contact surface: Tin
- Material: PA (Polyamide)
- Flammability rating: UL 94 V-0
- Dimensions: Length 25.7mm, Height 15mm, Width 30.42mm
- Stripping length: 10mm
- Conductor cross section: Solid 0.2-2.5 mm², Flexible 0.2-2.5 mm², AWG 24-12
- Maximum load current: 12 A
- Standards: EN-VDE, cULus Recognized
- Environmental Compliance: China RoHS - unlimited use period
Buy the Phoenix Contact Series FKC 2,5/ 4-STF-5,08: FKC254STF508
Order the Phoenix Contact FKC254STF508 PCB connector online today for reliable, tool-free push-in connection and secure electrical contact. Designed with a 5.08mm pitch and rated for 12A and 320V, it ensures high performance and durability in electronic circuits. Its tin contact surface, UL V-0 flammability rating, and compact dimensions make it ideal for dense PCB layouts. Purchase now to benefit from fast delivery and support for complex wiring tasks with quick testing options and robust mechanical stability.
Get Phoenix Contact FKC254STF508 today—built for precision, quick installation, and long-lasting durability in electronic assembly applications.
Frequently Asked Questions
Where can I buy Phoenix Contact FKC254STF508?
You can click on the BUY or RFQ button to purchase FKC254STF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKC254STF508?
You can download the FKC254STF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKC254STF508?
Phoenix Contact
