Phoenix Contact FKC25HC3STF508 PCB Connector, 3-Position
The PHOENIX CONTACT FKC 2,5 HC/ 3-STF-5,08 is a robust and versatile PCB connector designed for efficient and reliable power transmission in a variety of industrial applications. Its push-in spring connection simplifies installation, eliminating the need for tools. The connector's defined contact force ensures long-term stability, while the color-coded actuation lever enhances usability. Integrated double steel spring provides added safety against temperature and power fluctuations, and the screwable flange offers superior mechanical stability. It is optimized for tight installation situations and allows for operation and conductor connection from a single direction. The integrated test option enables quick and convenient testing.
Phoenix Contact FKC25HC3STF508 PCB Connector, 3-Position Specifications:
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- GTIN: 4017918880262
- Weight per Piece (excluding packing): 6.840 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Length [ l ]: 25.73 mm
- Width [ w ]: 25.34 mm
- Height [ h ]: 15 mm
- Pitch: 5.08 mm
- Dimension a: 10.16 mm
- Range of articles: FKC 2,5 HC/..-STF
- Number of positions: 3
- Connection method: Push-in spring connection
- Insulating material group: I
- Rated surge voltage (III/3): 4 kV
- Rated surge voltage (III/2): 4 kV
- Rated surge voltage (II/2): 4 kV
- Rated voltage (III/3): 320 V
- Rated voltage (III/2): 320 V
- Rated voltage (II/2): 630 V
- Connection in acc. with standard: EN-VDE
- Nominal current IN: 16 A
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A (with a 2.5 mm² conductor cross section)
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A2
- Stripping length: 10 mm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1.5 mm²
- Minimum AWG according to UL/CUL: 26
- Maximum AWG according to UL/CUL: 12
- Note: In accordance with IEC 61984, COMBICON connectors have no switching power (COC). During designated use, they must not be plugged in or disconnected when carrying voltage or under load.
