Phoenix Contact FKCOR2510STF508 PCB connector
The FKCOR 2.5/10-STF-5.08 from Phoenix Contact is a 5.08 mm pitch, 10-pole female printed circuit board connector featuring a screw flange for enhanced mechanical stability. The connector's conductor connection is orthogonal to the operational direction, simplifying the cabling of DIN-rail-mountable devices. It supports quick and easy testing via an integrated testing option and can be combined with the MSTB 2.5 range connectors. The push-in spring connection with tin-plated contacts allows for tool-free, time-saving wiring. It is user-friendly, with a color-coded actuation lever, rated for a surge voltage of 4 kV, with rated voltages of 250 V (III/3), 320 V (III/2), and 630 V (II/2). The nominal current is 12 A, suitable for conductor cross-sections from 0.2 mm² to 2.5 mm² (stripping length of 10 mm) or 24 AWG to 12 AWG, making it ideal for industrial applications.
Phoenix Contact FKCOR2510STF508 PCB connector Specifications:
- Number of positions: 10
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V (III/2), 250 V (III/3), 630 V (II/2)
- Rated surge voltage: 4 kV
- Connection method: Push-in spring connection
- Contact surface: Tin-plated
- Conductor cross section: solid 0.2 mm² to 2.5 mm², AWG 24 to 12
- Stripping length: 10 mm
- Dimensions: Length 23.7 mm, Width 60.78 mm, Height 14.3 mm
- Material: Plastic housing, metal screw flange
- Environmental compliance: China RoHS
Buy the Phoenix Contact FKCOR2510STF508 – Reliable PCB Connector for Industrial Applications
Get your Phoenix Contact FKCOR 2.5/10-STF-5.08 printed circuit board connector online today. Featuring a 10-pole design, 5.08 mm pitch, and push-in spring connection, it offers fast, tool-free wiring with reliable tin-plated contacts. The connector's metal screw flange provides mechanical stability, making it suitable for DIN rail applications. Rated for 12 A and up to 320 V, it supports conductor cross-sections from 0.2 mm² to 2.5 mm² or 24 to 12 AWG. Purchase now for dependable, secure connections in your industrial systems.
Order your Phoenix Contact FKCOR 2.5/10-STF-5.08 connector today and ensure quick, secure wiring for your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR2510STF508?
You can click on the BUY or RFQ button to purchase FKCOR2510STF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR2510STF508?
You can download the FKCOR2510STF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR2510STF508?
Phoenix Contact
