Phoenix Contact FKCOR2512ST508LR Printed-circuit board connector
The Phoenix Contact FKCOR 2.5/12-ST-5.08-LR is a 12-pole female printed-circuit board connector with a 5.08mm pitch. It features an automatic locking mechanism and an intuitive release lever with contrasting color for easy operation. The connector's conductor connection is orthogonal to the direction of insertion, simplifying cabling for DIN rail-mounted devices. It offers a quick, tool-free push-in connection with tin-plated spring contacts, and supports a rated surge voltage of 4kV. The rated voltages are 250V (III/3), 320V (III/2), and 630V (II/2). It handles a nominal current of 12A with a cross section range of 0.2mm² to 2.5mm² (24AWG to 12AWG) and requires a 10mm stripping length. Compatible with the MSTB 2.5 range connectors, this connector is suitable for industrial applications, providing easy testing and reliable connections.
Phoenix Contact FKCOR2512ST508LR Printed-circuit board connector Specifications:
- Number of positions: 12
- Pitch: 5.08 mm
- Rated voltage (III/2): 320 V
- Rated voltage (III/3): 250 V
- Rated voltage (II/2): 630 V
- Rated surge voltage: 4 kV
- Nominal current: 12 A
- Connection method: Push-in spring connection
- Conductor cross section: min 0.2 mm², max 2.5 mm² (AWG 24-12)
- Stripping length: 10 mm
- Dimensions: Length 29.1 mm, Width 69.96 mm, Height 14.7 mm
- Flammability: UL 94 V-0
- Material: Tin-plated contact surfaces
- Standards: EN-VDE standard compliance
Buy the Phoenix Contact Series FKCOR 12-Pole PCB Connector: FKCOR2512ST508LR
Enhance your industrial applications with the Phoenix Contact FKCOR 2.5/12-ST-5.08-LR, a high-quality 12-pole PCB connector. Designed with push-in spring technology, it allows quick, tool-free assembly, saving time and increasing efficiency. Its orthogonal conductor connection simplifies wiring, especially for DIN rail-mounted devices. With proven reliability, rated for 12A and up to 320V, it supports a wide range of cross sections from 0.2mm² to 2.5mm² (24-12 AWG). Made from durable materials, this connector ensures secure, vibration-resistant connections for automation and control systems and is compatible with MSTB 2.5 series modules.
Get Phoenix Contact FKCOR2512ST508LR today—built for easy mounting and reliable electrical connections in industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR2512ST508LR?
You can click on the BUY or RFQ button to purchase FKCOR2512ST508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR2512ST508LR?
You can download the FKCOR2512ST508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR2512ST508LR?
Phoenix Contact
