Phoenix Contact FKCOR256ST508 Printed Circuit Board Connector
The Phoenix Contact FKCOR 2.5/6-ST-5.08 is a six-pole printed-circuit board connector with a 5.08 mm pitch. It features an orthogonal conductor connection that simplifies wiring of DIN rail-mounted devices and offers quick, tool-free push-in connection with a color-coded actuation lever for easy operation. The connector has a tin-plated spring contact, rated surge voltage of 4 kV, and a rated voltage of up to 630 V depending on the category, with a nominal current of 12 A. It supports conductor cross sections from 0.2 mm² to 2.5 mm² (24-12 AWG) and requires a 10 mm stripping length, making it ideal for industrial automation and control systems.
Phoenix Contact FKCOR256ST508 Printed Circuit Board Connector Specifications:
- Number of positions: 6
- Pitch: 5.08 mm
- Rated voltage: 320 V (III/2), up to 630 V (varies)
- Rated surge voltage: 4 kV
- Nominal current: 12 A
- Conductor cross section: 0.2 mm² to 2.5 mm² (24-12 AWG)
- Connection method: Push-in spring connection
- Stripping length: 10 mm
- Contact surface: Tin-plated
- Dimensions: Length 23.7 mm, Width 30.35 mm, Height 14.3 mm
- Weight per piece: 2.220 g
Buy the Buy Phoenix Contact PCB Connector Part Number FKCOR256ST508 Online
Order the Phoenix Contact FKCOR 2.5/6-ST-5.08 online today to benefit from a robust and easy-to-use PCB connector ideal for industrial automation. Its push-in spring connection allows quick wiring without tools, while the orthogonal design simplifies installation in DIN rail-mounted devices. With a rated surge voltage of 4 kV, rated voltages up to 630 V, and a current capacity of 12 A, this connector offers high performance and durability. Its tin-plated contacts ensure excellent conductivity, making it a reliable choice for control cabinets, testing, and electronics projects. Purchase now for quick delivery and seamless integration into your systems.
Buy Phoenix Contact FKCOR256ST508 now and enjoy reliable, tool-free wiring for industrial automation and control systems.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR256ST508?
You can click on the BUY or RFQ button to purchase FKCOR256ST508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR256ST508?
You can download the FKCOR256ST508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR256ST508?
Phoenix Contact
