Phoenix Contact FKIC254ST508RN PCB Connector
The PHOENIX CONTACT FKIC 2 5/ 4-ST-5 08-RN is a versatile printed-circuit board connector ideal for applications requiring robust and reliable connections. Designed with a 5.08mm pitch and a push-in spring connection, it simplifies the wiring process and ensures secure termination. This connector is particularly well-suited for shock-proof applications when combined with inverted base strips and plugs. It supports a wide range of conductor sizes and is compatible with various marker cards for easy identification. Its robust construction and compliance with industry standards make it a dependable choice for industrial automation, control panels, and other demanding environments.
Phoenix Contact FKIC254ST508RN PCB Connector Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 320 V
- Number of positions: 4
- Pitch: 5.08 mm
- Connection method: Push-in spring connection
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Weight per Piece: 7.2 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Dimension a: 15.24 mm
- Insulating material group: I
- Rated surge voltage (III/3): 4 kV
- Rated surge voltage (III/2): 4 kV
- Rated surge voltage (II/2): 4 kV
- Range of articles: FKIC 2,5/..-ST-RN
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 26
- Maximum AWG according to UL/CUL: 12
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A2
- Stripping length: 10 mm
Buy the FKIC 2 5/ 4-ST-5 08-RN PHOENIX CONTACT PCB Connector | myMectronic
Purchase the PHOENIX CONTACT FKIC 2 5/ 4-ST-5 08-RN PCB Connector securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact FKIC254ST508RN?
You can click on the BUY or RFQ button to purchase FKIC254ST508RN from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKIC254ST508RN?
You can download the FKIC254ST508RN datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKIC254ST508RN?
Phoenix Contact
