Phoenix Contact FMC154ST381 PCB connector
The FMC 1,5/ 4-ST-3,81 is a printed-circuit board connector designed for safe, reliable, and quick connections in electronic assemblies. It features a push-in spring connection method requiring no tools, ensuring stable contact over time with a defined contact force. The connector has four positions with a pitch of 3.81 mm, rated current of 8 A, and a rated voltage of 160 V. Its tin contact surface guarantees excellent electrical conductivity. Designed for efficient front-end device integration, it offers user-friendly color-coded actuation levers for intuitive operation and quick wiring.
Phoenix Contact FMC154ST381 PCB connector Specifications:
- Number of positions: 4
- Connection method: Push-in spring connection
- Rated current: 8 A
- Rated voltage: 160 V (III/2), 320 V (Il/2), 2.5 kV surge voltage
- Pitch: 3.81 mm
- Dimensions: Length 21.9 mm, Height 7.8 mm, Width 15.73 mm, Dimension a 11.43 mm
- Contact surface: Tin
- Insulating material: PA
- Flammability rating: UL 94 V-0
- Wire cross section: 0.2-1.5 mm² (solid and flexible), AWG 24-16
- Mounting: Front and wave soldering options available
- Compliance: EN-VDE, UL, cULus, EAC, CB Scheme
- Environmental: Unlimited use period, No hazardous substances above thresholds
Buy the Buy Phoenix Contact FMC 1,5/ 4-ST-3,81 Part Number FMC154ST381 Online
Order the Phoenix Contact FMC 1,5/ 4-ST-3,81 printed-circuit board connector today for efficient, stable, and tool-free wiring solutions. This connector features a push-in spring connection, rated at 8 A and 160 V, with a pitch of 3.81 mm, designed for quick installation and long-term stability. Its tin contact surface ensures high electrical conductivity. Suitable for front-end device connection, the connector's color-coded actuation levers make wiring intuitive and fast, reducing assembly time. Perfect for professional electronic applications requiring reliable, secure connections.
Get Phoenix Contact FMC 1,5/ 4-ST-3,81 today—built for reliable PCB connections with easy push-in technology and durable contact surfaces.
Frequently Asked Questions
Where can I buy Phoenix Contact FMC154ST381?
You can click on the BUY or RFQ button to purchase FMC154ST381 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FMC154ST381?
You can download the FMC154ST381 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FMC154ST381?
Phoenix Contact
