Phoenix Contact FRONTMC1513ST381 PCB Connector 13 Position
The PHOENIX CONTACT FRONT-MC 1,5/13-ST-3,81 is a versatile printed circuit board connector designed for robust and reliable connections in a variety of industrial applications. This connector features a front screw connection, simplifying wiring and ensuring a secure connection. The generously dimensioned wiring space allows for easy conductor insertion and management. Individual position coding can be implemented by removing the coding tab and connecting the coding profile to the header, providing flexibility in circuit design. It is suitable for applications requiring a compact and reliable connection solution, such as automation systems, control panels, and power distribution.
Phoenix Contact FRONTMC1513ST381 PCB Connector 13 Position Specifications:
- Packing unit: 1 pc
- GTIN: N/A
- Weight per Piece (excluding packing): 17.16 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Height: 12.3 mm
- Width: 50.32 mm
- Pitch: 3.81 mm
- Dimension a: 45.72 mm
- Range of articles: FRONT-MC 1,5/..-ST
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 160 V
- Rated voltage (III/2): 160 V
- Rated voltage (II/2): 320 V
- Connection in acc. with standard: EN-VDE
- Nominal current IN: 8 A
- Nominal cross section: 1.5 mm²
- Maximum load current: 8 A (with 1.5 mm² conductor cross section)
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A1
- Stripping length: 9 mm
- Number of positions: 13
- Screw thread: M2
- Tightening torque, min: 0.22 Nm
- Tightening torque max: 0.25 Nm
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 1.5 mm²
- Conductor cross section flexible min.: 0.14 mm²
- Conductor cross section flexible max.: 1.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 1.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 0.5 mm²
- Conductor cross section AWG min.: 28
- Conductor cross section AWG max.: 16
- 2 conductors with same cross section, solid min.: 0.14 mm²
- 2 conductors with same cross section, solid max.: 0.5 mm²
- 2 conductors with same cross section, stranded min.: 0.14 mm²
- 2 conductors with same cross section, stranded max.: 0.75 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve max.: 0.34 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve max.: 0.5 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 16
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27260701
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440309
- eCl@ss 9.0: 27440309
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002638
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
Buy the FRONT-MC 1,5/13-ST-3,81 PHOENIX CONTACT PCB Connector 13 Position | myMectronic
Purchase the PHOENIX CONTACT FRONT-MC 1,5/13-ST-3,81 securely and efficiently for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact FRONTMC1513ST381?
You can click on the BUY or RFQ button to purchase FRONTMC1513ST381 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FRONTMC1513ST381?
You can download the FRONTMC1513ST381 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FRONTMC1513ST381?
Phoenix Contact
