Phoenix Contact GIC25HCV12ST762 PCB Connector, 12 Positions
The Phoenix Contact GIC 2,5 HCV/12-ST-7,62 is a high-performance PCB connector engineered for demanding industrial environments. It offers a 12-position configuration with a 7.62mm pitch, facilitating efficient space utilization on printed circuit boards. The screw connection with tension sleeve ensures a secure and reliable electrical connection, minimizing the risk of disconnections. This connector is ideal for applications requiring high current transmission, such as power distribution, motor control, and automation systems. Its robust design and ease of use make it a preferred choice for engineers and technicians seeking dependable connectivity solutions.
Phoenix Contact GIC25HCV12ST762 PCB Connector, 12 Positions Specifications:
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- GTIN: 4046356309875
- Weight per Piece (excluding packing): 27.960 g
- Custom tariff number: 85366990
- Country of origin: Slovakia
- Length l: 22.8 mm
- Width w: 91.22 mm
- Height h: 17.5 mm
- Pitch: 7.62 mm
- Dimension a: 83.82 mm
- Range of articles: GIC 2,5 HCV/..-ST
- Number of positions: 12
- Connection method: Screw connection with tension sleeve
- Insulating material group: I
- Rated surge voltage III/3: 8 kV
- Rated surge voltage III/2: 8 kV
- Rated surge voltage II/2: 8 kV
- Rated voltage III/3: 1000 V
- Rated voltage III/2: 1000 V
- Rated voltage II/2: 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal current IN: 16 A
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 8 mm
- Screw thread: M3
- Tightening torque min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min: 0.2 mm²
- Conductor cross section solid max: 2.5 mm²
- Conductor cross section flexible min: 0.2 mm²
- Conductor cross section flexible max: 2.5 mm²
- Conductor cross section flexible with ferrule without plastic sleeve min: 0.25 mm²
- Conductor cross section flexible with ferrule without plastic sleeve max: 2.5 mm²
- Conductor cross section flexible with ferrule with plastic sleeve min: 0.25 mm²
- Conductor cross section flexible with ferrule with plastic sleeve max: 2.5 mm²
- Conductor cross section AWG min: 24
- Conductor cross section AWG max: 12
- 2 conductors with same cross section solid min: 0.2 mm²
- 2 conductors with same cross section solid max: 1 mm²
- 2 conductors with same cross section stranded min: 0.2 mm²
- 2 conductors with same cross section stranded max: 1.5 mm²
- 2 conductors with same cross section stranded ferrules without plastic sleeve min: 0.25 mm²
- 2 conductors with same cross section stranded ferrules without plastic sleeve max: 1 mm²
- 2 conductors with same cross section stranded TWIN ferrules with plastic sleeve min: 0.5 mm²
- 2 conductors with same cross section stranded TWIN ferrules with plastic sleeve max: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
