Phoenix Contact GINSN38S68LPNESBK Cable Gland N3/8
The PHOENIX CONTACT G-INS-N3/8-S68L-PNES-BK cable gland is designed for robust industrial applications requiring a reliable and environmentally sealed cable connection. Constructed from PA material, it offers excellent chemical resistance and durability. The gland features a 3/8" NPT connecting thread, suitable for a wide range of industrial equipment and machinery. Its IP68 rating ensures protection against dust and water ingress, making it ideal for harsh environments. The gland is easily assembled with a flat nut and counter nut, ensuring a secure and leak-proof seal. It is commonly used in automation, control systems, and electrical distribution panels where reliable cable connections are critical.
Phoenix Contact GINSN38S68LPNESBK Cable Gland N3/8 Specifications:
- Packing unit: 1 pc
- Minimum order quantity: 10 pc
- GTIN: 4046356922920
- Weight per Piece (excluding packing): 10.000 g
- Custom tariff number: 39269097
- Country of origin: Turkey
- Length: 44 mm
- Wrench size, union nut: 22 mm
- Wrench size, support: 22 mm
- Hexagon angular dimension: 25 mm
- Length of the connecting thread: 15 mm
- External cable diameter: 5 mm ... 10 mm
- Degree of protection (IP): IP68 (5 bar / 0.5 h), IP66
- Ambient temperature (operation): -40 °C ... 100 °C (static)
- No. of conductors: 1
- Cable gland material: PA
- Cable seal material: CR
- Flammability rating according to UL 94: V2
- Shielded: no
- Thread type on connection side: 3/8" NPT
- Torque: 2.5 Nm
- Color: jet black RAL 9005
- Assembly instructions: Mount screw connection support in the housing using the correct torque, Insert cable, Tighten union nut using the correct torque
- Manufacturer: BIMED
- Manufacturer Designation: BSPA-21
- Halogen-free: no
- Connection in acc. with standard: CSA
- China RoHS: Environmentally friendly use period: unlimited = EFUP-e, No hazardous substances above threshold values
- eCl@ss 4.0: 27141200
- eCl@ss 4.1: 27141200
- eCl@ss 5.0: 27149100
- eCl@ss 5.1: 27149100
- eCl@ss 6.0: 27149100
- eCl@ss 7.0: 27149109
- eCl@ss 8.0: 27149109
- eCl@ss 9.0: 27144432
- ETIM 4.0: EC000441
- ETIM 5.0: EC000441
- ETIM 6.0: EC000441
- ETIM 7.0: EC000441
- UNSPSC 13.2: 39121311
- UNSPSC 18.0: 39121311
- UNSPSC 19.0: 39121311
- UNSPSC 20.0: 39121311
- UNSPSC 21.0: 39121311
