Phoenix Contact GMSTB256ST PCB connector
The GMSTB 2.5/6-ST is a printed-circuit board connector designed for reliable electrical connections in industrial applications. It features a screw connection method with a tension sleeve for secure contact, rated for 12 A current and 630 V voltage. The connector has 6 positions with a pitch of 7.5 mm, made from flame-retardant PA insulating material, and contact surface tin-plated for durability. Suitable for wave soldering, it is recognized under various international standards including UL, VDE, and CSA, ensuring high safety and quality standards for industrial wiring and automation systems.
Phoenix Contact GMSTB256ST PCB connector Specifications:
- Number of positions: 6
- Pitch: 7.5 mm
- Rated voltage: 630 V (III/2), 400 V (III/3), 1000 V (IV/2)
- Rated current: 12 A
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin-plated
- Insulating material: PA (Polyamide)
- Dimension a: 37.5 mm
- Screw thread: M3
- Tightening torque: 0.5 to 0.6 Nm
- Compatible with solid and stranded conductors from 0.2 mm² to 2.5 mm²
- Flammability rating: UL 94 V-0
- Standards: UL, VDE, CSA recognized, EN compliance
Buy the Phoenix Contact Series GMSTB PCB Connector: GMSTB256ST
Order the Phoenix Contact GMSTB256ST PCB connector online today for secure, reliable electrical connections in your industrial wiring projects. Designed with a screw connection, 12 A rated current, and 630 V capacity, it features a 7.5 mm pitch and tin-plated contacts for durability and corrosion resistance. Made from flame-retardant PA, it adheres to UL, VDE, and CSA standards, ensuring safety and quality. Ideal for automation systems, its wave soldering compatibility allows easy installation in manufacturing environments. Buy now for dependable performance.
Get Phoenix Contact GMSTB256ST today—built for precise connections and long-lasting durability in industrial automation.
Frequently Asked Questions
Where can I buy Phoenix Contact GMSTB256ST?
You can click on the BUY or RFQ button to purchase GMSTB256ST from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMSTB256ST?
You can download the GMSTB256ST datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMSTB256ST?
Phoenix Contact
