Phoenix Contact GMSTB25HCV3ST762 Terminal Block Plug Connector
The Phoenix Contact GMSTB 2.5 HCV/ 3-ST-7,62 plug connector is a versatile component designed for reliable electrical connections in industrial environments. Its compact 7.62 mm pitch maximizes space utilization, while the double steel spring provides added safety against temperature and power fluctuations. With a nominal current carrying capacity of 16A and a voltage rating up to 1000V, this connector is suitable for a wide range of applications including power distribution, automation, and control systems. The connector accepts conductor cross-sections ranging from 0.2 mm² to 2.5 mm², ensuring compatibility with various wiring configurations. Its robust construction and secure connection method contribute to long-term reliability and reduced maintenance requirements.
Phoenix Contact GMSTB25HCV3ST762 Terminal Block Plug Connector Specifications:
- Base Article No.: 1714281
- Nominal Current: 16 A
- Rated Voltage (III/2): 1000 V
- Number of Positions: 3
- Pitch: 7.62 mm
- Connection Method: Screw connection with tension sleeve
- Color: green
- Contact Surface: Tin
- Packing Unit: 1 pc
- Minimum Order Quantity: 50 pc
- Weight Per Piece: 6.67 g
- Custom Tariff Number: 85366990
- Country of Origin: Germany
- Dimension a: 15.24 mm
- Insulating Material Group: I
- Rated Surge Voltage (III/3): 8 kV
- Rated Surge Voltage (III/2): 8 kV
- Rated Surge Voltage (II/2): 8 kV
- Nominal Cross Section: 2.5 mm²
- Maximum Load Current: 16 A
- Flammability Rating (UL 94): V0
- Internal Cylindrical Gage: A3
- Stripping Length: 8 mm
- Screw Thread: M3
- Tightening Torque (min): 0.5 Nm
- Tightening Torque (max): 0.6 Nm
- Conductor Cross Section Solid (min): 0.2 mm²
- Conductor Cross Section Solid (max): 2.5 mm²
- Conductor Cross Section Flexible (min): 0.2 mm²
- Conductor Cross Section Flexible (max): 2.5 mm²
- Conductor Cross Section Flexible with Ferrule (min): 0.25 mm²
- Conductor Cross Section Flexible with Ferrule (max): 2.5 mm²
- Conductor Cross Section AWG (min): 24
- Conductor Cross Section AWG (max): 12
- 2 Conductors Solid (min): 0.2 mm²
- 2 Conductors Solid (max): 1 mm²
- 2 Conductors Stranded (min): 0.2 mm²
- 2 Conductors Stranded (max): 1.5 mm²
- 2 Conductors Stranded with Ferrule (min): 0.25 mm²
- 2 Conductors Stranded with Ferrule (max): 1 mm²
- 2 Conductors Stranded TWIN Ferrule (min): 0.5 mm²
- 2 Conductors Stranded TWIN Ferrule (max): 1 mm²
- Minimum AWG (UL/CUL): 30
- Maximum AWG (UL/CUL): 12
- Connection Standard: EN-VDE
Buy the GMSTB 2 5 HCV/ 3-ST-7 62 PHOENIX CONTACT Terminal Block Plug Connector | myMectronic
Purchase the Phoenix Contact GMSTB 2 5 HCV/ 3-ST-7 62 plug connector securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact GMSTB25HCV3ST762?
You can click on the BUY or RFQ button to purchase GMSTB25HCV3ST762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMSTB25HCV3ST762?
You can download the GMSTB25HCV3ST762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMSTB25HCV3ST762?
Phoenix Contact
