Phoenix Contact GMVSTBR253ST762 PCB Connector
The GMVSTBR 2,5/ 3-ST-7,62 is a printed-circuit board connector designed for reliable electrical connections in industrial and automation applications. It features a screw connection with tension sleeve, rated for 12 A and a voltage of 630 V (III/2). The connector has three positions with a pitch of 7.62 mm, tin-plated contact surface, and a compact design measuring 26 mm in length. It complies with various standards for safety and environment, offering secure, easy installation and high durability for electronics and PCB assemblies.
Phoenix Contact GMVSTBR253ST762 PCB Connector Specifications:
- Number of positions: 3
- Pitch: 7.62 mm
- Length: 26 mm
- Height: 12.6 mm
- Width: 20.82 mm
- Rated current: 12 A
- Rated voltage: 630 V (III/2)
- Contact surface: Tin
- Connection method: Screw connection with tension sleeve
- Insulating material: PA
- Flammability rating: UL 94 vo
- Screw thread: M3
- Tightening torque: min 0.5 Nm, max 0.6 Nm
- Conductor cross section: solid 0.2–2.5 mm², flexible 0.2–2.5 mm², AWG 24–12
- Standards: EN-VDE, CSA, UL recognized, VDE approved, cULus recognized
- Rated surge voltage: 6 kV
- Environmental compliance: China RoHS
Buy the Buy Phoenix Contact PCB Connector Part Number GMVSTBR253ST762 Online
Order the Phoenix Contact GMVSTBR 2,5/ 3-ST-7,62 connector online for dependable, high-quality PCB connections. Featuring a screw connection with tension sleeve, rated for 12 A and 630 V, this compact connector ensures secure, stable electrical contact. Its tin-plated contact surface offers corrosion resistance, and the easy-to-install design reduces assembly time. Suitable for industrial automation, it adheres to international standards including UL, CSA, and VDE. Purchase now to enhance your electronic system’s reliability, safety, and long-term durability with trusted Phoenix Contact solutions.
Get Phoenix Contact GMVSTBR 2.5/3-ST-7.62 today—designed for secure connections, high current capacity, and reliable PCB assembly performance.
Frequently Asked Questions
Where can I buy Phoenix Contact GMVSTBR253ST762?
You can click on the BUY or RFQ button to purchase GMVSTBR253ST762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMVSTBR253ST762?
You can download the GMVSTBR253ST762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMVSTBR253ST762?
Phoenix Contact
