Phoenix Contact GMVSTBW253ST762 PCB Connector, 3 Positions
The PHOENIX CONTACT GMVSTBW 2 5/ 3-ST-7 62 is a versatile printed-circuit board connector designed for a wide range of industrial applications. This connector features a 7.62mm pitch and utilizes a screw connection with a tension sleeve, ensuring a secure and reliable connection. It is suitable for applications requiring robust power transmission and is designed to accommodate conductors ranging from 0.2 mm² to 2.5 mm². The connector's tin-plated contacts and PA insulating material contribute to its durability and performance. Its compact design and ease of use make it a valuable component in various electronic systems.
Phoenix Contact GMVSTBW253ST762 PCB Connector, 3 Positions Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 630 V
- Number of positions: 3
- Pitch: 7.62 mm
- Connection method: Screw connection with tension sleeve
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 7.48 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Rated surge voltage (III/3): 6 kV
- Rated surge voltage (III/2): 6 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 500 V
- Rated voltage (II/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Stripping length: 7 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27260701
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440309
- eCl@ss 9.0: 27440309
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002638
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
