Phoenix Contact GMVSTBW255ST762 PCB Connector, Screw Terminal
The PHOENIX CONTACT GMVSTBW 2,5/ 5-ST-7,62 is a versatile printed-circuit board connector designed for reliable connections in a variety of industrial applications. Featuring a screw connection with a tension sleeve, this connector ensures secure and stable electrical contact. With a nominal current of 12A and a rated voltage of 630V, it's suitable for demanding environments. The connector's design allows for vertical plug-in direction relative to the conductor axis, and conductor entry on the rippled side of the plug. It is ideal for applications requiring robust and dependable power transmission.
Phoenix Contact GMVSTBW255ST762 PCB Connector, Screw Terminal Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 630 V
- Number of positions: 5
- Pitch: 7.62 mm
- Connection method: Screw connection with tension sleeve
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 12.32 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Rated surge voltage (III/3): 6 kV
- Rated surge voltage (III/2): 6 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 500 V
- Rated voltage (II/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 7 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
