Phoenix Contact IC2516STGF508 PCB connector
This printed-circuit board connector features 16 positions with a 5.08 mm pitch, rated for 12 A and 320 V in accordance with EN-VDE standards. It employs screw connection with tension sleeve for secure wiring, has a tin contact surface, and is made from PA insulating material. The connector is suitable for PCB mounting, offers high mechanical stability with screwable flange, and is recognized under multiple standards including UL, CSA, and VDE. It's ideal for reliable electronic and automation connections with minimal temperature rise and easy PCB replacement.
Phoenix Contact IC2516STGF508 PCB connector Specifications:
- Number of positions: 16
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V (EN-VDE), 250 V (UL)
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin
- Material: PA insulating material
- Dimensions: Length 19.2 mm, Height and Width as per standard, insulation material group: PA
- Flammability rating: UL 94 V-0
- Tightening torque: 0.5 to 0.6 Nm
- Conductor cross section: Solid 0.2 to 2.5 mm², AWG 24-12
Buy the Phoenix Contact Series IC 2,5/16-STGF-5,08: IC2516STGF508
Purchase the Phoenix Contact PCB connector with 16 positions and a 5.08 mm pitch today. Designed for 12 A and 320 V, it features screw connection with tension sleeve, tin contacts, and robust PA insulation material. Its high mechanical stability and compliance with UL, CSA, and VDE standards make it ideal for dependable electronic circuits. Easy to replace on PCB, it ensures safe and reliable connections with minimal temperature rise, perfect for automation and industrial electronics projects. Order now for quick delivery and quality you can trust.
Order your Phoenix Contact Series IC 2,5/16-STGF-5,08 connector today and ensure reliable and easy PCB connections for industrial automation applications.
Frequently Asked Questions
Where can I buy Phoenix Contact IC2516STGF508?
You can click on the BUY or RFQ button to purchase IC2516STGF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part IC2516STGF508?
You can download the IC2516STGF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of IC2516STGF508?
Phoenix Contact
