Phoenix Contact KDS10SO Datasheet & Stock

This is a PCB terminal block rated for a nominal current of 76 A and a rated voltage of 320 V (category III/2). It features a cross-sectional capacity of 10 mm², a pitch of 10 mm, and a single position. The connection is made via screw terminals with tension sleeves, suitable for wave soldering mounting processes. The conductor-to-PCB connection is arranged at 0°, with a linear pin layout. Solder pins have a length of 4.3 mm. The design allows for configurable positioning to create multiple connection points.

View KDS10SODatasheet [pdf]
