Phoenix Contact LPC63ST762 Printed-circuit board connector
The LPC 6/3-ST-7,62 is a compact printed-circuit board connector designed for reliable and quick connections in electronic assemblies. It features push-in spring connections, a 7.62 mm pitch, and a green housing with tin-plated contacts, rated for 4A and 1000 V. The connector supports solid and stranded conductors from 0.75 mm² to 6 mm², ensuring stable long-term contact stability. Suitable for automation, control systems, and electronic devices, it offers efficient wiring with polarized insertion for easy assembly and maintenance.
Phoenix Contact LPC63ST762 Printed-circuit board connector Specifications:
- Pitch: 7.62 mm
- Number of positions: 3
- Rated current: 4A
- Rated insulation voltage: 1000 V
- Rated surge voltage: 8 kV
- Conductor cross section (solid/flexible): 0.75 mm² ... 6 mm²
- Conductor cross section (AWG): 18 ... 10
- Contact material: Cu alloy
- Surface: hot-dip tin-plated, 4-8 µm Sn
- Housing color: green (6021)
- Length: 48 mm
- Width: 24.86 mm
- Dimensions: a: 15.24 mm, b: 4.3 mm x 4.0 mm / 4.0 mm diameter
- Protection class: IP20
- Compliance: WEEE/RoHS, IEC standards
- Temperature rating: up to 100°C
- Number of cycles: 25
- Test forces: insertion approx 11 N, withdrawal approx 16 N
Buy the Phoenix Contact Series LPC: Printed-circuit board connector LPC 6/ 3-ST-7,62
Order the Phoenix Contact LPC 6/3-ST-7,62 connector online today for precise, secure, and long-lasting electronic connections. Featuring push-in spring technology and a compact design, this connector ensures quick wiring and reliable contact stability for automation, control, and electronic device applications. Its 7.62 mm pitch, rated for 4A and 1000 V, makes it suitable for various industrial and electronic systems. Enjoy fast delivery, quality assurance, and competitive pricing when you buy from authorized distributors online.
Get Phoenix Contact LPC 6/3-ST-7,62 today—built for reliable electronic connections and quick wiring in control panels and automation systems.
