Phoenix Contact LPT163100ZB PCB Terminal Block
This PCB terminal block features a lever push-in connection for quick, tool-free wiring, supporting conductor cross-sections from 0.75 mm² to 16 mm². It has a 10 mm pitch with 3 positions arranged in zigzag pin layout, suitable for wave soldering mounting. The green housing is made of flame-retardant PA, with a rated voltage of 1000 V and a nominal current of 76 A. Its robust tin-plated copper contact ensures reliable long-term connections, making it ideal for high-current industrial electronics and power distribution applications.
Phoenix Contact LPT163100ZB PCB Terminal Block Specifications:
- Nominal current: 76 A
- Rated voltage: 1000 V
- Conductor cross section: 0.75 mm² to 16 mm²
- Push-in connection for easy wiring
- Pitch: 10 mm
- Number of positions: 3
- Mounting: Wave soldering
- Housing color: Green
- Housing material: PA (Polyamide)
- Contact material: Copper alloy, tin-plated
- Stripping length: 18 mm to 20 mm
- Dimensions: Width 32 mm, height variables, solder pin length unspecified
- Minimum clearances: 8 mm (IIV/3), 5.5 mm (IIV/2), creepage distance 8-12.5 mm
- Operating temperature: -40°C to 105°C
- Flammability rating: UL 94 V-0
- Certifications: IEC 60068-2-82, RoHS compliant
Buy the Buy Phoenix Contact PCB Terminal Block Part Number LPT163100ZB Online
Purchase the Phoenix Contact PCB terminal block LPT 16/ 3-10,0-ZB online today for efficient, high-current connections in industrial control systems. Featuring a tool-free lever push-in connection, it simplifies wiring and offers long-lasting stability with tin-plated copper contacts. The compact 10 mm pitch supports 3 positions for versatile circuit design, with a green flame-retardant housing suitable for wave soldering. Achieve reliable, safe, and maintenance-friendly electrical connections ideal for demanding control and power applications.
Get Phoenix Contact LPT 16/ 3-10,0-ZB today—built for high-current power distribution with reliable, tool-free lever operation.
Frequently Asked Questions
Where can I buy Phoenix Contact LPT163100ZB?
You can click on the BUY or RFQ button to purchase LPT163100ZB from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part LPT163100ZB?
You can download the LPT163100ZB datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of LPT163100ZB?
Phoenix Contact
