Phoenix Contact LPT164100ZB PCB Terminal Block
The PCB terminal block LPT 16/ 4-10,0-ZB is a compact, wave-soldered connection component designed for reliable, quick leverage push-in connections with clear status feedback. It supports a nominal current of 76 A and rated voltage of 1000 V, featuring lever push-in connection for easy conductor attachment. Its zigzag pin layout enhances contact stability, with flexible cross-section handling from 0.75 mm² to 16 mm². Ideal for industrial PCB applications requiring secure, time-efficient connections in a green insulating housing.
Phoenix Contact LPT164100ZB PCB Terminal Block Specifications:
- Nominal current: 76 A
- Rated voltage: 1000 V
- Number of potentials: 4
- Number of positions per row: 4
- Pitch: 10 mm
- Mounting: Wave soldering
- Connection method: Lever push-in
- Conductor cross section: 0.75 mm² to 16 mm² (solid and stranded), flexible 0.75 mm² to 25 mm²
- Stripping length: 18 mm to 20 mm
- Housing color: Green (6021)
- Housing material: PA
- Flammability rating: UL 94 V-0
- Contact material: Copper alloy, tin-plated
- Dimensions: Width varies, length 32 mm, height specified according to design
- Hole diameter for PCB: 1.7 mm
- Ambient temperature (operation): -40 °C to 105 °C
- Creepage distance: 8 mm to 12.5 mm
- Clearances: Minimum 5.5 mm to 8 mm
Buy the Buy Phoenix Contact PCB Terminal Block Part Number LPT164100ZB Online
Purchase the Phoenix Contact PCB terminal block LPT 16/ 4-10,0-ZB online to ensure reliable, quick connections for your electrical assemblies. This terminal supports a current of 76 A, rated at 1000 V, with a compact design suitable for wave soldering and industrial PCB applications. Its lever push-in connection allows for easy wire installation and removal, saving time and reducing labor costs. The zigzag pin layout guarantees long-term contact stability, while the green housing provides visual clarity for quick inspections. Order now for professional-grade connection solutions.
Get Phoenix Contact PCB Terminal Block LPT 16/ 4-10,0-ZB today—designed for secure, fast, and long-lasting circuit connections.
Frequently Asked Questions
Where can I buy Phoenix Contact LPT164100ZB?
You can click on the BUY or RFQ button to purchase LPT164100ZB from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part LPT164100ZB?
You can download the LPT164100ZB datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of LPT164100ZB?
Phoenix Contact
