Phoenix Contact MC156ST1508 PCB Connector
This printed-circuit board connector is designed for reliable electrical connections with a 6-position Female connector featuring a 5.08 mm pitch. It supports a nominal current of 8 A and rated voltage of 320 V, suitable for various industrial applications. Constructed with a PA insulator and a tin contact surface, it ensures maximum contact force and low temperature rise. The screw connection with tension sleeve provides secure fastening, and the compact dimensions make it ideal for space-constrained environments. Approved by VDE, cULus, and other standards, it guarantees safety and durability.
Phoenix Contact MC156ST1508 PCB Connector Specifications:
- Number of positions: 6
- Pitch: 5.08 mm
- Rated current: 8 A
- Rated voltage: 320 V
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin
- Insulating material: PA (Polyamide)
- Maximum load current: 8 A
- Screw thread: m2
- Tightening torque: 0.22 Nm to 0.25 Nm
- Conductor cross section: solid 0.14 mm² to 1.5 mm²
- Flexible conductors: min 0.14 mm², max 1.5 mm²
- Wire gauge: AWG 28 to 16
- Flammability rating: UL 94 V-0
Buy the Buy Phoenix Contact PCB Connector Part Number MC156ST1508 Online
Discover the reliable Phoenix Contact PCB connector with 6 positions, 5.08 mm pitch, and 8 A current capacity. Made with a durable PA insulator and tin contact surface, it ensures secure connections in various industrial settings. Approved by VDE, cULus, and other standards, this connector supports space-efficient designs with screw connection technology. Ideal for professionals seeking long-lasting, safe, and high-performance PCB wiring solutions, this product can be conveniently purchased online for quick installation and dependable operation in demanding environments.
Get Phoenix Contact MC156ST1508 today—designed for secure, reliable industrial PCB connections with high-quality screw termination.
Frequently Asked Questions
Where can I buy Phoenix Contact MC156ST1508?
You can click on the BUY or RFQ button to purchase MC156ST1508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MC156ST1508?
You can download the MC156ST1508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MC156ST1508?
Phoenix Contact
