Phoenix Contact MCDN155G135P26THR 5 Position Pin Strip
The PHOENIX CONTACT MCDN 1,5/ 5-G1-3,5 P26THR is a versatile pin strip designed for through-hole reflow soldering (THR) applications. Its compact design and low-profile double-level pins make it ideal for space-constrained environments and flush mounting on devices. This pin strip is suitable for a wide range of industrial applications, including connecting components to PCBs in electronics manufacturing and automation systems. The pin strip supports a nominal current of 8A and a rated voltage of 160V, ensuring reliable performance in demanding environments. It is manufactured in Bulgaria and complies with EN-VDE standards.
Phoenix Contact MCDN155G135P26THR 5 Position Pin Strip Specifications:
- Nominal current: 8 A
- Rated voltage (III/2): 160 V
- Number of positions: 5
- Pitch: 3.5 mm
- Color: black
- Contact surface: Tin
- Mounting: THR soldering
- Pin length: 2.6 mm
- Pin dimensions: 0,8 x 0,8 mm
- Pin spacing: 3.50 mm
- Hole diameter: 1.4 mm
- Constructional height: 16 mm
- Height: 15.2 mm
- Length: 13.3 mm
- Dimension a: 14 mm
- Insulating material group: IIIa
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 160 V
- Rated voltage (II/2): 250 V
- Connection in acc. with standard: EN-VDE
- Maximum load current: 8 A (per position)
- Insulating material: LCP
- Flammability rating according to UL 94: V0
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 3.81 g
- Custom tariff number: 85366990
- Country of origin: Bulgaria
- Range of articles: MCDN 1,5/..-G1-THR
