Phoenix Contact MSTBA2510G508LR pcb terminal block
The MSTBA 2.5/10-G-5.08-LR is a compact, green mounting header designed for PCB connections with a rated current of 12 A and a voltage of 320 V. It features ten positions with a 5.08 mm pitch, made from flame-retardant PBT material, with tin-plated contact surfaces for reliable conductivity. Suitable for soldering, this component complies with WEEE/RoHS standards, making it ideal for industrial or automation applications requiring robust, space-efficient terminal blocks with precise hole diameters and high load capacity.
Phoenix Contact MSTBA2510G508LR pcb terminal block Specifications:
- Number of positions: 10
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Contact surface: Tin-plated
- Material: PBT insulating material
- Color: Green
- Hole diameter: 1.4 mm
- Pin length: 12 mm
- Height: 11.9 mm
- Length: 45.72 mm
- Flammability: UL 94V-0
- Rated surge voltage: 4 kV
- Certificate: cULus Recognized
Buy the Buy Phoenix Contact MSTBA 2.5/10-G-5.08-LR Part Number MSTBA2510G508LR Online
Order the Phoenix Contact MSTBA 2.5/10-G-5.08-LR today for a dependable, space-saving connector. Featuring 10 positions, a 5.08 mm pitch, and a rated current of 12 A at 320 V, it offers high load capacity with tin-plated contacts for optimal conductivity. Its flame-retardant PBT housing ensures durability in industrial environments. Suitable for soldering, and compliant with RoHS, it’s ideal for automation, control systems, or PCB wiring tasks requiring precise, secure connections that are easy to install and highly reliable.
Get Phoenix Contact MSTBA 2.5/10-G-5.08-LR today—designed for reliable PCB connections with high current capacity and RoHS compliance.
Frequently Asked Questions
Where can I buy Phoenix Contact MSTBA2510G508LR?
You can click on the BUY or RFQ button to purchase MSTBA2510G508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MSTBA2510G508LR?
You can download the MSTBA2510G508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MSTBA2510G508LR?
Phoenix Contact
