Phoenix Contact OPT60DC24DC2 PLC Interface Relay
The PHOENIX CONTACT PLC-BSC series is a super-thin, plug-in modular interface system designed to address common issues in industrial automation, such as interference voltages and leakage currents affecting relay performance. This interface features an integrated filter circuit that significantly reduces interference in the control circuit, ensuring safe and reliable signal transmission. It's ideal for applications involving long cables or electronic AC outputs, where conventional relays may fail due to external noise or leakage currents. The system offers a user-friendly jumper system, vibration resistance, and quick relay/optocoupler replacement, making it a versatile solution for various PLC applications.
Phoenix Contact OPT60DC24DC2 PLC Interface Relay Specifications:
- Input Voltage U N: 120 V AC, 230 V AC
- Permissible Range: 0.8…1.4 (120 V AC), 0.78…1.14 (230 V AC)
- Typical Release Voltage: 50 V AC, 80 V AC
- Typical Input Current at U N (50 Hz/60 Hz): 7/8 mA, 8.8/10 mA
- Typical Response/Release Time: 7 ms/20 ms
- Contact Version: Single contact, 1 Form C contact
- Contact Material: AgSnO, Ag alloy (hard gold-plated)
- Maximum Switching Voltage: 250 V AC/DC
- Minimum Switching Voltage: 30 V AC/36 V DC
- Limiting Continuous Current: 12 V AC/DC
- Maximum Inrush Current: 6 A
- Minimum Switching Current: 50 mA
- Minimum Switching Power: 120 mW, 100 µ W
- Flammability Class: V0 according to UL 94
- Mechanical Life: 2 x 10^7 cycles
- Ambient Operating Temperature Range: -20°C to +55°C
- Mounting Position: Any
Buy the OPT-60DC/ 24DC/ 2 PHOENIX CONTACT PLC Interface Relay | myMectronic
Secure your PHOENIX CONTACT OPT-60DC/ 24DC/ 2 PLC Interface Relay today and ensure reliable operation in your industrial setup.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact OPT60DC24DC2?
You can click on the BUY or RFQ button to purchase OPT60DC24DC2 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part OPT60DC24DC2?
You can download the OPT60DC24DC2 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of OPT60DC24DC2?
Phoenix Contact
