Phoenix Contact PTCM056PI25WH Printed Circuit Board Connector
The PTCM 0.5/6-PI-2.5 WH is a compact printed-circuit board connector designed for reliable crimp connections with a rated current of 6 A and rated voltage of 160 V. Featuring a pitch of 2.5 mm and six positions, it is suitable for PCB applications requiring touch-proof device outputs or loose cable connections. The white housing is stable during welding and operation, with options for manual or automated crimping. It complies with IEC and UL standards, ensuring high safety, durability, and ease of installation for industrial and electronics manufacturing environments.
Phoenix Contact PTCM056PI25WH Printed Circuit Board Connector Specifications:
- Rated current: 6 A
- Rated voltage (IEC/UL): 160 V
- Number of positions: 6
- Pitch: 2.5 mm
- Connection method: Crimp connection
- Conductor cross section: 0.14 mm² … 0.75 mm² (AWG 26 ... 18)
- Insulating material: PA (Polyamide)
- Flammability rating: UL 94 V-0
- Glow wire flammability index: GWFI 850
- Glow wire ignition temperature: GWIT 775°C
- Temperature resistance: Up to 125°C
- Ingress protection: IP20
- Dimensions: Approximate length 15 mm, width 4.5 mm, height 10 mm
- Solder tab dimensions: Typical 2.5 mm)
- Connector fitting, weight per piece: 0.8 g
Buy the Buy Phoenix Contact PCB Connector Part Number PTCM056PI25WH Online
Order the Phoenix Contact PTCM 0.5/6-PI-2.5 WH PCB connector online today to ensure secure, high-quality connections in your electronic designs. This reliable, compact connector features a 2.5 mm pitch, is rated for 6 amps and 160 volts, and supports crimping with manual or automatic tools. Its robust white housing maintains stability during welding and operation, meeting IEC and UL standards, making it ideal for industrial applications, electronics manufacturing, and control systems. Purchase now for quick delivery and trusted performance.
Buy Phoenix Contact PTCM 0.5/6-PI-2.5 WH now and experience high reliability with durable crimp connections for your PCB needs.
