Phoenix Contact PTDA25350 PCB terminal block
This PCB terminal block features a 3-position configuration with a 5 mm pitch, ensuring reliable push-in spring connection for quick, tool-free installation. It supports a nominal current of 24 A and voltage of 400 V, with wave soldering mounting and a conductor connection angle of 45°. Constructed from PA material, it has a flammability rating of UL 94 V-0, with a compact design including 10 solder pins to reduce mechanical stress. Ideal for industrial applications, it provides high reliability and efficient wiring solutions.
Phoenix Contact PTDA25350 PCB terminal block Specifications:
- Pitch: 5 mm
- Number of positions: 3
- Rated current: 24 A
- Rated voltage: 400 V
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Conductor cross section: solid 0.2 mm² to 2.5 mm², flexible 0.2 mm² to 2.5 mm²
- Material: PA (Polyamide)
- Flammability rating: UL 94 V-0
- Solder pin surface: Sn (tin)
- Flammability rating: UL 94 V-0
- Dimensions: Length varies, pin length suitable for wave soldering, hole diameter fits AWG 24-14
- Rated surge voltage: 4 kV
- Certifications: UL Recognized, VDE approved, cUL recognized
Buy the Buy Phoenix Contact PCB Terminal Block Part Number PTDA25350 Online
Enhance your wiring setup with this high-quality PCB terminal block, featuring a 3-position configuration, 5 mm pitch, and push-in spring connection. Designed for reliable, tool-free installation, it supports 24 A/400 V ratings, made from flame-retardant PA material, and suited for wave soldering. Its compact design includes 10 solder pins, reducing stress on solder joints. Ideal for industrial automation, control panels, and complex wiring systems, this connector ensures dependable performance in demanding environments. Purchase online today for fast delivery and excellent technical support.
Buy Phoenix Contact PTDA25350 now and experience unmatched reliability and performance with quick push-in connection and durable construction for industrial wiring.
Frequently Asked Questions
Where can I buy Phoenix Contact PTDA25350?
You can click on the BUY or RFQ button to purchase PTDA25350 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part PTDA25350?
You can download the PTDA25350 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of PTDA25350?
Phoenix Contact
