Phoenix Contact SMKDS1435 PCB Terminal Block
The PCB terminal block SMKDS 1/4-3,5 offers reliable screw connection with tension sleeve, rated for 10 A current and 200 V voltage, featuring a 3.5 mm pitch and 4 positions. Its compact design allows multi-row PCB mounting and supports wave soldering. Made from high-quality PA insulation with Sn-plated solder pins, it complies with UL 94V-0 flammability standards. With dimensions including a length of 10 mm, width of 14.5 mm, and a construction height of 9.5 mm, it is suitable for various industrial and automation applications.
Phoenix Contact SMKDS1435 PCB Terminal Block Specifications:
- Number of positions: 4
- Rated current: 10 A
- Rated voltage: 200 V
- Pitch: 3.5 mm
- Length: 10 mm
- Width: 14.5 mm
- Construction height: 9.5 mm
- Pin dimensions: 0.5 x 0.9 mm
- Hole diameter: 1.4 mm
- Solder pin length: 3.5 mm
- Conductor cross section: solid min. 0.14 mm², max. 1.5 mm²
- Flexible conductor: min. 0.14 mm², max. 1 mm²
- Flexible with ferrule: min. 0.25 mm², max. 0.5 mm²
- Conductor AWG: min. 26, max. 16
- Screw thread: M2
- Tightening torque: 0.22 Nm to 0.25 Nm
- Flammability rating: UL 94V-0
- Insulating material: PA
- Standards: EN-VDE, CSA
- Rated surge voltage: 2.5 kV
- Ambient temperature: -40°C to +105°C
Buy the Phoenix Contact SMKDS 1/4-3,5 – Reliable PCB Terminal Block for Industrial Applications
Order the Phoenix Contact PCB terminal block SMKDS 1/4-3,5 online today for reliable, safe, and efficient connections in industrial automation. Designed with a 3.5 mm pitch and rated for 10 A and 200 V, it supports easy wave soldering and multi-row PCB mounting. Made from high-quality PA insulation and Sn-plated pins, it guarantees durability and compliance with safety standards. Perfect for automation, control panels, and wiring applications, this compact terminal block ensures secure connections, reducing installation time and increasing system reliability. Buy now for optimal performance and long-term value.
Get Phoenix Contact SMKDS 1/4-3,5 today—built for precision, safety, and long-lasting durability in industrial automation and PCB wiring systems.
Frequently Asked Questions
Where can I buy Phoenix Contact SMKDS1435?
You can click on the BUY or RFQ button to purchase SMKDS1435 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part SMKDS1435?
You can download the SMKDS1435 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of SMKDS1435?
Phoenix Contact
