Phoenix Contact SPTD156H35 PCB Terminal Block
This PCB terminal block offers a reliable push-in spring connection for easy and tool-free conductor attachment, supporting high contact density with multiple levels connection. Designed for industrial applications, it features a 3.5 mm pitch, 6 positions, and a grounding-friendly design. The terminal block is suitable for wave soldering and adheres to EN-VDE standards, with a rated voltage of up to 200 V and a current capacity of 10 A. Constructed from durable PA insulation with tin-plated solder pins, it ensures long-term stability and environmental compliance, including China RoHS certification.
Phoenix Contact SPTD156H35 PCB Terminal Block Specifications:
- Number of positions: 6
- Pitch: 3.5 mm
- Rated current: 10 A
- Rated voltage: 200 V
- Conductor cross section solid: 0.14–1.5 mm²
- Conductor cross section flexible: 0.14–1.5 mm²
- Flexible with ferrule without plastic sleeve: 0.2–1.5 mm²
- Flexible with ferrule with plastic sleeve: 0.2–0.75 mm²
- Wire cross section AWG: 26–16
- Pin dimensions: 0.6 x 1.0 mm
- Pin spacing: 9.35 mm
- Hole diameter: 1.3 mm
- Insulation material: PA
- Flammability rating: UL 94 vo
- Rated surge voltage: 2.5 kV
- Solder pin surface: Sn
- Stripping length: 8 mm
- Standards: EN-VDE
- Environmental compliance: China RoHS
Buy the Phoenix Contact SPTD156H35 – Reliable PCB Terminal Block for Industrial Applications
Enhance your industrial wiring with the reliable Phoenix Contact PCB terminal block, featuring a push-in design for quick, tool-less connections. Suitable for wave soldering, it offers high contact density with 6 positions at a 3.5 mm pitch, rated for 10 A and 200 V. Made from durable PA insulation with tin-plated pins, it meets EN-VDE standards and environmental regulations including China RoHS. Perfect for manufacturing, automation, and control panels, this high-quality terminal block ensures long-term stable connections, simplifying assembly and maintenance.
Order your Phoenix Contact Series SPTD156H35 today and secure high-density, tool-free wiring for your industrial electronic projects.
Frequently Asked Questions
Where can I buy Phoenix Contact SPTD156H35?
You can click on the BUY or RFQ button to purchase SPTD156H35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part SPTD156H35?
You can download the SPTD156H35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of SPTD156H35?
Phoenix Contact
