Phoenix Contact TDPT253SC508 PCB Terminal Block
This PCB terminal block offers reliable screw connection with tension sleeve, suitable for wave soldering, with a 5.08 mm pitch and 3 positions. Made from copper alloy with hot-dip tin plating, it supports a rated current of 24 A and voltage of 400 V. Its compact dimensions include a length of 18 mm, width of 16.04 mm, and height of 19 mm, with a pin spacing of 8.7 mm. It features linear double pinning, and is designed for easy installation and high durability in electronic and automation applications. Its green housing enhances visibility and installation accuracy.
Phoenix Contact TDPT253SC508 PCB Terminal Block Specifications:
- Pitch: 5.08 mm
- Number of positions: 3
- Connection method: Screw connection with tension sleeve
- Rated current: 24 A
- Rated voltage: 400 V
- Conductor cross section (solid): 0.2 mm² ... 4 mm²
- Conductor cross section (flexible): 0.2 mm² ... 2.5 mm²
- Wiring: 10 mm stripping length
- Material: Copper alloy, hot-dip tin-plated
- Housing color: Green
- Dimensions: Length 18 mm, Width 16.04 mm, Height 19 mm
- Pin spacing: 8.7 mm
- Solder pin length: 3.5 mm
- Solder pin dimensions: 0.9 x 0.9 mm
- Standards: EN-VDE, UL 94 VO flammability
- Rated surge voltage: 4 kV
- Insulating material group: I
Buy the Buy Phoenix Contact PCB Terminal Block Part Number TDPT253SC508 Online
Order the Phoenix Contact PCB terminal block with 3 positions and 5.08 mm pitch today. This high-quality, wave solder-compatible component features a screw connection, rated for 24 A and 400 V, providing secure and durable electrical connections. Its copper alloy, hot-dip tin-plated contacts ensure excellent conductivity, while a compact size and green housing facilitate easy installation and visibility. Perfect for automation, electronics, and industrial applications, this terminal block combines reliability, precision, and ease of use, making it an essential component for your assembly needs.
Get Phoenix Contact TDPT253SC508 today—designed for reliable, high-current connections in industrial and electronic assemblies.
Frequently Asked Questions
Where can I buy Phoenix Contact TDPT253SC508?
You can click on the BUY or RFQ button to purchase TDPT253SC508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part TDPT253SC508?
You can download the TDPT253SC508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of TDPT253SC508?
Phoenix Contact
