Phoenix Contact ZFKDS15508 PCB Terminal Block
This PCB terminal block is designed for reliable electrical connections with a nominal current of 16 A and a rated voltage of 400 V (III/2). It features a 1.5 mm² nominal cross-section, a pitch of 5.08 mm, and a single position. The connection method utilizes a spring-cage mechanism for secure attachment, suitable for wave soldering mounting. Conductor and PCB connection are at a 45° angle, with a green color coding and linear pin layout. The solder pins are 3.5 mm long. This is a single module that can be grouped with others of varying numbers of positions, and end terminal blocks are available for proper termination. Different configurations, including multiple positions, are also offered.
Phoenix Contact ZFKDS15508 PCB Terminal Block Specifications:
- Rated current: 16 A
- Rated voltage: 400 V (III/2)
- Nominal cross section: 1.5 mm²
- Pitch: 5.08 mm
- Connection method: Spring-cage
- Mounting: Wave soldering
- Conductor/PCB connection angle: 45°
- Color: Green
- Pin length: 3.5 mm
- Hole diameter: 1.3 mm
- Solder pin surface: Sn
- Flammability rating: UL 94 V-0
- Conductor cross section solid: 0.2–2.5 mm²
- Flexible conductor cross section: 0.2–1.5 mm²
- Conductor AWG: 24–14
- Materials: PA insulating material
Buy the Buy Phoenix Contact PCB Terminal Block Part Number ZFKDS15508 Online
Order the Phoenix Contact PCB Terminal Block ZFKDS 1,5-5,08 online today. This high-quality terminal features a 5.08 mm pitch, spring-cage connection, and 16 A current capacity. Its wave soldering compatibility makes it ideal for robust electronic assembly, while its 45° connection angle facilitates multi-row PCB arrangements. The green color coding enhances identification, and the durable Sn-plated solder pins ensure long-lasting electrical contact. Perfect for industrial controls, automation systems, and high-reliability electronic projects, this module offers excellent performance, easy installation, and flexible configurations. Purchase now to ensure dependable electrical connections.
Get Phoenix Contact ZFKDS15508 today—designed for secure, reliable, and easy-to-assemble electrical connections for industrial and automation applications.
Frequently Asked Questions
Where can I buy Phoenix Contact ZFKDS15508?
You can click on the BUY or RFQ button to purchase ZFKDS15508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part ZFKDS15508?
You can download the ZFKDS15508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of ZFKDS15508?
Phoenix Contact
