Phoenix Contact ZFKDS15C50 PCB Terminal Block
This PCB terminal block rated for 16 A and 400 V features a 1.5 mm² cross section, 5 mm pitch, and single position design. It employs a spring-cage connection, supports wave soldering, and connects conductors at a 45° angle. Its green color and linear pin layout facilitate easy installation and multi-row arrangements. Solder pins are 3.5 mm long, and the module is customizable with various position counts for flexible circuit designs. The terminal block conforms to UL standards and is suitable for various industrial and electronic applications, ensuring reliable connections and high durability.
Phoenix Contact ZFKDS15C50 PCB Terminal Block Specifications:
- Rated current: 16 A
- Rated voltage: 400 V (III/2)
- Cross section: 1.5 mm²
- Pitch: 5 mm
- Number of positions: 1
- Connection method: Spring-cage
- Mounting: Wave soldering
- Conductor connection angle: 45°
- Color: Green
- Pin length: 3.5 mm
- Pin dimensions: 0.7 x 0.7 mm
- Solder pin surface: Sn
- Insulating material: PA
- Standards: UL Recognized, cUL Recognized, EN-VDE
Buy the Phoenix Contact Series ZFKDS PCB Terminal Block: ZFKDS15C50
Purchase the Phoenix Contact PCB Terminal Block ZFKDS15C50 today to ensure robust, reliable electrical connections in your circuit assemblies. This high-quality terminal features a spring-cage connection system, supports wave soldering, and offers a 5 mm pitch with a single position design. Its green color and angled conductor connection facilitate multi-row arrangements, making it ideal for complex electronic and industrial applications. With UL and cUL recognition, this terminal provides long-term stability, optimal contact force, and ease of installation—perfect for demanding environments and versatile circuit configurations.
Buy Phoenix Contact ZFKDS15C50 now and experience unmatched reliability and performance for your PCB connection needs.
Frequently Asked Questions
Where can I buy Phoenix Contact ZFKDS15C50?
You can click on the BUY or RFQ button to purchase ZFKDS15C50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part ZFKDS15C50?
You can download the ZFKDS15C50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of ZFKDS15C50?
Phoenix Contact
