QUALTEK ELECTRONICS FAD104010CBMW11 Axial Fan
This high-performance 40x40x10mm brushless DC axial fan is designed for reliable cooling in electronic and industrial applications. It features UL 94V-0 rated plastic frame and impeller, with impedance protected motor for durability. Available with two ball or hydro dynamic bearings, it operates effectively at temperatures from -10°C to 70°C, providing up to 70,000 hours of life with minimal noise. This efficient cooling solution offers various speeds up to 6800 rpm, with adjustable airflow and pressure options, ideal for demanding electronic cooling needs.
QUALTEK ELECTRONICS FAD104010CBMW11 Axial Fan Specifications:
- Dimensions: 40x40x10mm
- Type: Brushless DC axial fan
- Frame Material: UL94V-0 plastic
- Impeller Material: UL94V-0 plastic
- Bearing Types: Two Ball or Hydro Dynamic
- Operating Temp: -10°C to 70°C
- Life Expectancy: Up to 70,000 hours (Two Ball), 50,000 hours (Hydro Dynamic)
- Rated Voltage: 5V or 12V DC
- Current: 0.040A to 0.160A depending on model
- Power: 0.48W to 1.08W
- Speed: 3300 to 6800 rpm
- Airflow: 3.3 to 7.0 CMM
- Noise Level: 14 to 29 dB
- Wire Length: 300mm UL 1007 AWG 26 wire leads
- Certifications: UL Listed
- Mounting: 4 mounting holes
- Application: Electronics cooling, industrial equipment
- Temperature Range: -10°C to 70°C
Buy the Buy Qualtek FAD1-04010 Series Part Number FAD104010CBMW11 Online
Enhance your cooling system with the high-quality Qualtek axial fan. Designed for durability and efficiency, this 40x40x10mm fan features UL 94V-0 rated plastic, multiple bearing options, and long operating hours. It ensures optimal airflow with minimal noise, ideal for electronics, industrial, and equipment cooling. The fan is easy to install, operates reliably at temperatures from -10°C to 70°C, and offers adjustable speeds up to 6800 rpm. Purchase online today for fast delivery and superior cooling performance.
Order your Qualtek SeriesFAD1-04010CBMW11 axial fan today and enhance your electronic cooling system with reliable and efficient airflow.
Frequently Asked Questions
Where can I buy QUALTEK ELECTRONICS FAD104010CBMW11?
You can click on the BUY or RFQ button to purchase FAD104010CBMW11 from an authorized QUALTEK ELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part FAD104010CBMW11?
You can download the FAD104010CBMW11 datasheet or visit the QUALTEK ELECTRONICS website for support.
Who is the manufacturer of FAD104010CBMW11?
QUALTEK ELECTRONICS
