RENESAS R5F104GEAFB30 Industrial Microcontroller
The R5F104GEAFB30 is a 40-pin microcontroller with an embedded flash memory of 384 KB supporting high-speed and low-speed operation modes, equipped with a versatile analog-to-digital converter with 10 channels, and multiple serial interfaces including UART, LIN-bus, and simplified I2C support. It features a 16-bit timer, watchdog timer, real-time clock, and multiple PWM outputs, making it suitable for industrial and consumer applications such as automation, sensor control, and communication systems, with robust reset, power management, and on-chip debug functions for reliable operation across temperature ranges from -40°C to +85°C.
RENESAS R5F104GEAFB30 Industrial Microcontroller Specifications:
- Package: 40-pin plastic HWQFN (7x7 mm, 0.5 mm pitch)
- Code Flash Memory: 384 KB (supporting 16 to 64 KB variants)
- Data Flash Memory: 8 KB
- RAM: 32 to 48 KB (start address FE900H)
- Address Space: 1 MB
- Main System Clock: 1 to 20 MHz (HS mode), 1 to 16 MHz (HS mode), 1 to 8 MHz (LS mode), 1 to 4 MHz (LV mode), Vop 2.7 to 5.5 V
- High-Speed On-Chip Oscillator: 1 to 32 MHz (HS mode), 1 to 16 MHz (HS mode), 1 to 8 MHz (LS mode), 1 to 4 MHz (LV mode)
- Subsystem Clock: 32.768 kHz (XT1 oscillation), internal oscillator 15 kHz (typical)
- Instruction Set: 8/16-bit data transfer, arithmetic, multiplication, division, bit manipulation
- Analog-to-Digital Converter: 8 or 10-bit, 8 channels
- Digital-to-Analog Converter: 2 channels
- Serial Interfaces: UART, LIN-bus, simplified I2C (up to 2 channels each)
- Timer: 16-bit, 8 channels, including PWM outputs
- Watchdog Timer: 1-channel
- Real-time Clock: 1-channel with 1Hz output
- Power Supply: 1.6 to 5.5 V
- Operating Temperature: -40°C to +85°C
- Additional Features: Reset circuits, voltage detector, on-chip debug, data flash programming, and low power modes.
Buy the Buy Renesas RL78/G14 Part Number R5F104GEAFB30 Online
Purchase the Renesas RL78/G14 R5F104GEAFB30 online today. This 40-pin microcontroller delivers 384KB flash memory, high-speed & low-speed operation modes, 10-channel ADC, serial interfaces, timer, RTC, PWM outputs, and extensive on-chip debug functions. It supports industrial and consumer applications including automation, sensor control, and communication systems, with reliable power management and temperature range from -40°C to +85°C. Designed for durability, perfect for developing robust embedded solutions with flexible clock options and extensive peripherals.
Get Renesas RL78/G14 microcontroller R5F104GEAFB30 today—built for industrial automation and reliable communication with versatile features.
Frequently Asked Questions
Where can I buy RENESAS R5F104GEAFB30?
You can click on the BUY or RFQ button to purchase R5F104GEAFB30 from an authorized RENESAS distributor.
How do I troubleshoot issues or seek technical support for part R5F104GEAFB30?
You can download the R5F104GEAFB30 datasheet or visit the RENESAS website for support.
Who is the manufacturer of R5F104GEAFB30?
RENESAS
