ROHM 2SAR533PFRAT100 Power Transistor
The 2SAR533P FRA is a high-speed, low saturation voltage middle power transistor suitable for low frequency amplifier and switching applications. It features a compact SOT-89 package, VcEO of -50V, and an Io of -3A, with a maximum power dissipation of 2.0 W. This transistor offers high DC current gain, fast switching times, and robust junction temperature limits, making it ideal for precise control and amplification in power circuits. Compliant with AEC-Q101 standards, it ensures quality and reliability for automotive and industrial electronics.
ROHM 2SAR533PFRAT100 Power Transistor Specifications:
- Package: SOT-89, SC-62 (A), MPT3
- Maximum collector-base voltage: -50 V
- Maximum collector-emitter voltage: -50 V
- Emitter-base voltage: 6 V
- Collector current: -3 A (up to 6 A pulsed)
- Power dissipation: 2.0 W
- Junction temperature: 150°C
- Storage temperature: -55°C to +150°C
- Transition frequency: 300 MHz
- Collector cutoff current: 1.0 pA
- Collector-emitter saturation voltage: -200 to -400 mV at -1A
- DC current gain: 180 to 450
- Turn-On time: 45 ns
- Fall time: 35 ns
- Emitter input capacitance: 4 pF
- Collector output capacitance: Variable, depending on Vce
- Dimensions: Patterned for SOT-89 package, detailed dimensions available on datasheet
Buy the ROHM Series MPT 2SAR533P: Middle Power Transistor
Order the ROHM 2SAR533P FRA power transistor online now for precise amplification and high-speed switching in low frequency amplifier and switching circuits. Designed for automotive and industrial use, it features a compact SOT-89 package, -50V collector-base voltage, -3A collector current, and a power dissipation of 2.0 W. Its high DC gain, fast transition times, and robust junction temperature rating ensure reliable performance in demanding electronic applications. Secure your stock today for quality and durability.
Get ROHM 2SAR533P FRA today—built for high-speed switching and reliable power control in industrial and automotive applications.
Frequently Asked Questions
Where can I buy ROHM 2SAR533PFRAT100?
You can click on the BUY or RFQ button to purchase 2SAR533PFRAT100 from an authorized ROHM distributor.
How do I troubleshoot issues or seek technical support for part 2SAR533PFRAT100?
You can download the 2SAR533PFRAT100 datasheet or visit the ROHM website for support.
Who is the manufacturer of 2SAR533PFRAT100?
ROHM
