ROHM PMR100HZPFU5L00 Ultra-low ohmic resistor
Ultra-low ohmic chip resistors designed for precise current detection, these resistors feature a trimming-ess structure for improved accuracy and a low temperature coefficient. With certifications including ISO9001, ISO, and TS16949, they offer reliable performance in automotive, industrial, and electronic applications. Available in various sizes from 0402 to 2512, they provide resistance ranges from 1mΩ to 3.2kΩ, with power ratings up to 2W. Their robustness against temperature cycling and static conditions makes them ideal for demanding environments.
ROHM PMR100HZPFU5L00 Ultra-low ohmic resistor Specifications:
- Size: 1005 (0402), Rated Power: 0.2 W
- Resistance Range: 1mΩ to 10Ω
- Tolerance: ±1%, ±4%, ±5%
- Temperature Coefficient: Special low resistance temperature coefficient, typically ±45ppm/°C
- Operating Temperature: -55°C to +155°C
- Resistance Tolerance: ±1%, ±4%, ±5%
- Certification: ISO9001, ISO, TS16949, AEC-Q200 (PMR01 in preparation)
- Dimensions: Length 1.00mm +0.05mm, Width 0.50mm +0.05mm
- Material: Metal film, conductive low-ohmic resistor
- Special Features: Minimal thermal stress during temperature cycling, improved current detection accuracy
Buy the ROHM PMR100HZPFU5L00 – Reliable Ultra-low Ohmic Resistors for Industrial Applications
Discover the dependable quality of the ROHM ultra-low ohmic resistor PMR100HZPFU5L00. Engineered for high accuracy and reliability in current sensing applications, this resistor features a low temperature coefficient and excellent thermal cycling stability. Its compact size and robust specifications make it suitable for automotive, industrial, and electronic projects requiring precise resistance measurement. Order online now and ensure your devices operate at peak performance with ROHM’s precision resistors, backed by certified quality and advanced design.
Order your ROHM SeriesPMR100HZPFU5L00 ultra-low ohmic resistor today and enhance your current detection accuracy with dependable industrial-grade performance.
Frequently Asked Questions
Where can I buy ROHM PMR100HZPFU5L00?
You can click on the BUY or RFQ button to purchase PMR100HZPFU5L00 from an authorized ROHM distributor.
How do I troubleshoot issues or seek technical support for part PMR100HZPFU5L00?
You can download the PMR100HZPFU5L00 datasheet or visit the ROHM website for support.
Who is the manufacturer of PMR100HZPFU5L00?
ROHM
