Red Lion Controls RPGBIM01 Rotary Encoder
The model ZPJ large thru-bore rotary pulse generator is a high-precision encoder with a 0.625-inch bore, ideal for industrial automation, offering up to 2500 PPR, quadrature output, and IP64 sealing. Designed with all-metal construction, it features NPN open collector outputs, flexible mountings, and extensive environmental resistance, including operability from 0°C to 70°C, vibration, shocks, and humidity. Suitable for applications requiring reliable, low-cost position sensing with precise mechanical and electrical specifications, making it perfect for machinery and automation systems requiring high-speed rotation and accurate incremental signals.
Red Lion Controls RPGBIM01 Rotary Encoder Specifications:
- Supply Voltage: 4.75 to 28 VDC, 100 mA max.
- Outputs: NPN Open Collector, Voy = 30 VDC max., 20 mA max.
- Maximum Frequency: 200 KHz
- Bore Size: 0.625 inches (15.875 mm)
- Sealing: IP64
- Operating Temperature: 0°C to +70°C
- Storage Temperature: -40°C to +100°C
- Vibration: 10 g @ 58 to 500 Hz
- Shock: 50 g @ 11 msec duration
- Housing Material: Non-corrosive metal
- Maximum Mechanical Speed: 7500 RPM
- Mounting: Flex arm 1.06 to 1.81 inches radius
- Cable Length: 36 inches (914.4 mm)
- Dimensions: Approximately 0.73 inches (18.54 mm) in diameter, with mounting hole details for installation
- Accuracy: Within 0.01° mechanical, 0.6 arc minutes
- Quadrature Phase: 90° (+22.5°) electrical
- Index Pulse: Once per revolution over output channel A
Buy the Red Lion Series ZPJ Rotary Encoder: RPGBIM01
Order the Red Lion Rotary Encoder RPGBIM01 online today to ensure precise position feedback in your machinery and automation systems. This encoder offers high-resolution pulses up to 2500 PPR, robust metal housing, IP64 sealing, and dependable NPN open collector outputs. Its versatile mounting options and wide temperature range make it suitable for demanding industrial environments. Take advantage of quick online purchasing to boost your equipment's accuracy, reliability, and efficiency—perfect for applications requiring high-speed rotation and precise incremental signals.
Buy Red Lion RPGBIM01 now and experience unmatched reliability and performance with high-resolution, industrial-grade rotation sensing.
Frequently Asked Questions
Where can I buy Red Lion Controls RPGBIM01?
You can click on the BUY or RFQ button to purchase RPGBIM01 from an authorized Red Lion Controls distributor.
How do I troubleshoot issues or seek technical support for part RPGBIM01?
You can download the RPGBIM01 datasheet or visit the Red Lion Controls website for support.
Who is the manufacturer of RPGBIM01?
Red Lion Controls
