STMICROELECTRONICS LNBH25LSPQR Satellite Control IC
The LNBH25LS is a highly efficient satellite receiver control IC with integrated step-up and I2C interface. Designed in a compact QFN24 (4x4 mm) package, it provides versatile power supply options including a built-in DC-DC converter for 13/18 V output and ability to generate 22 kHz signals for satellite LNBs. It offers selectable current limits, programmable output voltages, robust overload and thermal protections, ESD tolerance, and essential diagnostic functions. Suitable for set-top boxes, satellite TV receivers, and PC satellite cards, the IC simplifies design with low component count and reliable operation in satellite systems.
STMICROELECTRONICS LNBH25LSPQR Satellite Control IC Specifications:
- Package: QFN24 (4x4 mm)
- Supply Voltage: 8 to 16 V
- Output Voltages: 13 V and 18 V programmable levels (VSEL1-4)
- Output Current Limit: 350-750 mA selectable via external resistor RSEL
- Built-in DC-DC step-up converter: Efficiency ~93% at 0.5 A
- 22 kHz Tone Generator: Accurate, factory trimmed, suitable for DiSEqC
- Protections: Overload, overtemperature, short-circuit, ESD (±4 kV)
- Diagnostic Functions: Overtemperature (OTF), overload (OLF), input voltage (PNG)
- I2C Interface: 2-wire standard, with address selection
- Thermal Resistance: Junction to ambient approximately 40 °C/W with PCB vias
- Operating temperature: -25°C to 125°C
- ESD Tolerance: ±4 kV on output pins
