STMICROELECTRONICS PNUCLEO53L0A1 Distance and Gesture Sensor
The P-NUCLEO-53L0A1 evaluation pack combines the VL53L0X Time-of-Flight distance sensor with a detailed gesture detection capability, integrated into an expandable system featuring the STM32F401RE microcontroller. It includes two VL53L0X satellite boards, a 4-digit display for real-time distance readings, and supports simple gesture recognition applications. The system offers precise absolute ranging independent of target reflectance, making it suitable for robotics, automation, and sensor-based projects, with full software support from STMicroelectronics.
STMICROELECTRONICS PNUCLEO53L0A1 Distance and Gesture Sensor Specifications:
- Sensor Technology: Time-of-Flight (ToF)
- Measurement Range: Up to several meters (dependent on environment)
- Target Reflectance Independence: Yes
- Sensor Type: VL53L0X laser-ranging sensor with FlightSense™ technology
- Microcontroller: STM32F401RE Nucleo Board
- Display: 4-Digit, shows distance in cm
- Power Supply: 2.8V regulator on expansion board
- Interfaces: I2C (SCL, SDA), UART (for debugging), GPIOs for interrupts
- Connectivity: Arduino UNO R3 compatible connectors for easy expansion
- Laser Class: Class 1 laser safety compliant
- Dimensions: Supports spacers of 0.25 mm, 0.5 mm, 1 mm to simulate air gaps
- Board Material: RoHS compliant, standard electronic components
- Software: Full system software available from ST’s website
- Compliance: RoHS, IEC 60825-1:2014 laser safety
- Environmental: ECOPACK® compliant packaging
Buy the STMicroelectronics P-NUCLEO-53L0A1 – Reliable Distance Measurement for Industrial Applications
Enhance your projects with the STMicroelectronics distance and gesture sensor system. The P-NUCLEO-53L0A1 offers high-precision laser ranging, gesture detection, and easy expansion with STM32 microcontrollers. Ideal for robotics, automation, and smart device applications, this comprehensive kit includes two VL53L0X satellite boards, a 4-digit display, and full software support. Designed with environmentally friendly ECOPACK® packaging, it ensures safety and reliability for all your sensing needs. Purchase online today to accelerate your development process and achieve outstanding results.
Buy STMicroelectronics P-NUCLEO-53L0A1 now and experience unmatched reliability and performance with precise laser-ranging and gesture detection capabilities.
Frequently Asked Questions
Where can I buy STMICROELECTRONICS PNUCLEO53L0A1?
You can click on the BUY or RFQ button to purchase PNUCLEO53L0A1 from an authorized STMICROELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part PNUCLEO53L0A1?
You can download the PNUCLEO53L0A1 datasheet or visit the STMICROELECTRONICS website for support.
Who is the manufacturer of PNUCLEO53L0A1?
STMICROELECTRONICS
