STMICROELECTRONICS STM8S003K3T6C Embedded Microcontroller
The STM8S003K3T6C is a high-performance 8-bit microcontroller operating at 16 MHz, equipped with a Harvard architecture core, 8 KB Flash memory, 128-byte EEPROM, and a 10-bit ADC with ±1 LSB accuracy. It features a nested interrupt controller supporting up to 32 interrupts, including 27 external across 6 vectors, and multiple timers such as advanced control, general purpose, and basic timers. The device includes UART, SPI, and I2C communication interfaces, up to 28 I/O pins with 21 high-sink outputs, and an embedded single-wire interface for fast in-circuit programming and debugging. Low-power modes and clock security system enhance energy efficiency and reliability, making it suitable for embedded applications requiring efficient control and communications.
STMICROELECTRONICS STM8S003K3T6C Embedded Microcontroller Specifications:
- Core: 8-bit STM8, Harvard architecture, 3-stage pipeline
- Operating Voltage: 2.95 V to 5.5 V
- Flash Memory: 8 KB with 20 years data retention at 55 °C
- EEPROM: 128 bytes, endurance up to 100,000 cycles
- Clock: Internal RC oscillators 16 MHz and 128 KHz low-power RC
- Multiple timers: 16-bit advanced control, 16-bit general purpose, 8-bit basic timer
- Communication: UART (full-featured), SPI (up to 8 Mbit/s), I2C (up to 400 Kbit/s)
- Analog: 10-bit ADC with up to 5 channels, scan mode, analog watchdog
- I/O pins: Up to 28 total, including 21 high-sink outputs
- Debugging: Embedded single-wire interface (SWIM) for fast programming
- Power modes: Wait, active-halt, halt; with individual peripheral clock management
- Interrupts: Nested, 32 vectors, 27 external interrupts
- Protection: Read-out protection (ROP), user option byte area, write protection
Buy the Buy STMicroelectronics STM8S003K3T6C Microcontroller Part Number STM8S003K3T6C Online
Purchase the STMicroelectronics STM8S003K3T6C microcontroller online today and benefit from its high-performance 8-bit core, integrated 10-bit ADC, multiple communication interfaces, and multiple low-power modes. Its extensive I/O pin count, embedded debugging features, and robust protection mechanisms ensure reliable operation in embedded systems. Whether for motor control, sensor data processing, or automation tasks, this device offers flexibility and efficiency, making it an ideal choice for designers seeking a versatile, energy-efficient microcontroller for their innovative projects.
Buy STMicroelectronics STM8S003K3T6C microcontroller now and experience reliable embedded control with advanced timers, communication interfaces, and debugging support.
Frequently Asked Questions
Where can I buy STMICROELECTRONICS STM8S003K3T6C?
You can click on the BUY or RFQ button to purchase STM8S003K3T6C from an authorized STMICROELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part STM8S003K3T6C?
You can download the STM8S003K3T6C datasheet or visit the STMICROELECTRONICS website for support.
Who is the manufacturer of STM8S003K3T6C?
STMICROELECTRONICS
