SAMTEC SQT10401LD high-reliability connector
The product features a high-reliability connector series with vertical and right-angle options, constructed from black liquid crystal polymer insulator material and phosphor bronze contact material. It offers a current rating of 5.1 A per pin, voltage rating of 450 VAC, and operates within a temperature range of -55°C to +125°C. The contact resistance is 10 mΩ, with insertion depths from 2.62 mm to 5.03 mm. It supports up to 100 mating cycles, is RoHS compliant, and lead-free, with tin or gold plating over nickel. Suitable for high-density electronic assemblies, it ensures durability and performance in demanding environments.
SAMTEC SQT10401LD high-reliability connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Sn or Au over 50u" Nickel
- Current Rating: 5.1 A per pin
- Voltage Rating: 450 VAC
- Operating Temp Range: -55°C to +125°C
- Contact Resistance: 10 mΩ
- Insertion Depth: 2.62 mm to 5.03 mm (0.103" to 0.198")
- Insertion Force: 402 (1.11 N) (single contact)
- Normal Force: 60 grams (0.59 N)
- Withdrawal Force: 3.07 (0.83 N) (single contact)
- Max Cycles: 100
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
Buy the Samtec Series SQT: High-Performance Connector Series SQT-107-02-L-S
Discover the versatile high-reliability connector designed for demanding electronic assemblies. Featuring black liquid crystal polymer insulators and phosphor bronze contacts, it offers excellent electrical performance with a current rating of 5.1 A per pin and a voltage rating of 450 VAC. Its operating temperature range from -55°C to +125°C, RoHS compliance, and lead-free construction ensure durability and safety. Suitable for vertical and right-angle configurations, supporting up to 100 mating cycles, this connector delivers excellent connection stability and longevity for industrial and electronic applications.
Buy Samtec SQT-107-02-L-S now and experience unmatched reliability and performance in high-density electronic applications.
Frequently Asked Questions
Where can I buy SAMTEC SQT10401LD?
You can click on the BUY or RFQ button to purchase SQT10401LD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SQT10401LD?
You can download the SQT10401LD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SQT10401LD?
SAMTEC
