SAMTEC SSQ11401TSLL High-Temperature Socket
This product is a through-hole socket designed for electrical connections in high-temperature environments. Made with black liquid crystal polymer insulator material and phosphor bronze contact material, it features gold or tin plating options. It supports current ratings of 6.3 A per pin and 47 A per power pin, with a voltage rating of 465 VAC or 655 VDC. The socket offers various insertion depths, standard force is 125 grams, and it operates over a temperature range of -55°C to +125°C with gold plating. Suitable for multiple rows and options, it is RoHS compliant and lead-free solderable.
SAMTEC SSQ11401TSLL High-Temperature Socket Specifications:
- Insulator Material: Black Liquid Crystal Polymer (-S&-D) or Black High Temperature Thermoplastic (-T)
- Contact Material: Phosphor Bronze
- Plating: Gold or Tin with 50 micro inches (1.27 um) Ni
- Current Rating: 6.3 A per pin, 47 A per power pin
- Voltage Rating: 465 VAC / 655 VDC
- Operating Temperature Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Insertion Depth: 3.68 mm, 6.35 mm
- Standard Force: 125 grams (4.4 N)
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Supported Rows: Single, Double, Triple
- Max Pins: 36 per row (varies by style), various lead styles available
- Compatibility: Mates with TSW, MTSW, MTLW, ZW, TSS, ZSS, TSM, TSSH, HTSS
- Notch options available, some lengths and styles are non-standard and non-returnable
Buy the Samtec Series SSQ Socket: SSQ11401TSLL
Purchase the Samtec Series SSQ high-temperature through-hole socket online today. Designed for reliable electrical connections, it features gold or tin plating, RoHS compliance, and supports up to 47 A current. Its versatile options include various insertion depths, row configurations, and lead styles, making it suitable for complex electronic assemblies. With its insulated material and broad temperature range, this socket ensures durability and performance in demanding environments. Buy now to enhance your electrical system’s reliability and achieve optimal performance.
Order your Samtec Series SSQ SSQ11401TSLL socket today and ensure reliable high-temperature electrical connections for your projects.
Frequently Asked Questions
Where can I buy SAMTEC SSQ11401TSLL?
You can click on the BUY or RFQ button to purchase SSQ11401TSLL from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSQ11401TSLL?
You can download the SSQ11401TSLL datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSQ11401TSLL?
SAMTEC
