SAMTEC SSW11302SDRA High-Temperature Socket
The SSW-125-01-G-S series is a high-temperature through-hole socket with a 0.025-inch square post, designed for reliable connection in electronic assemblies. Made from black liquid crystal polymer or high-temperature thermoplastic insulators, it features phosphor bronze contacts with gold or tin plating, supporting current ratings up to 6.3A per pin. It withstands temperatures from -55°C to +105°C and offers various optional plating, notch, and angle configurations for diverse applications. This contact socket ensures durable, RoHS-compliant connections with easy soldering and installation.
SAMTEC SSW11302SDRA High-Temperature Socket Specifications:
- Post Size: 0.025 inch square
- Insulator Material: Black Liquid Crystal Polymer or High-Temperature Thermoplastic
- Contact Material: Phosphor Bronze with gold or tin plating
- Current Rating: 6.3 A per pin
- Operating Temperature: -55°C to +105°C
- Voltage Rating: 465 VAC / 655 VDC
- RoHS Compliance: Yes
- Lead-Free: Yes
- Insertion Depth: 3.68 mm to 6.35 mm
- Contact Plating: 50 μ
- Dimensions: Length varies with option, typical tail length approximately 4.0 mm and insulator thickness 0.030 inches
- Material: Phosphor Bronze with gold or tin plating, insulator made from Liquid Crystal Polymer or high-temperature thermoplastic
- Voltage Rating: 465 VAC / 655 VDC
- Operating Temperature Range: -55°C to +105°C
- RoHS and lead-free compliant
- Insertion Depth: 3.68 mm to 6.35 mm
- Current Support: 6.3 A per pin
- Certifications: Recognized for quality and standards, RoHS compliant, suitable for durable electronic connections
Buy the Buy Samtec SSW-125-01-G-S High-Temperature Socket Part Number SSW11302SDRA Online
Purchase the Samtec High-Temperature Socket SSW-125-01-G-S online today to experience durable, RoHS compliant connections with excellent current support. This socket's robust design features a 0.025-inch square post, high-performance phosphor bronze contacts with gold or tin plating, and versatile options such as notch and angle configurations. Designed to operate within -55°C to +105°C, it supports 6.3A per pin, making it ideal for demanding electronic applications requiring reliable connectivity and heat resistance. Secure your inventory now for optimal project performance.
Order your Samtec SeriesSSW-125-01-G-S socket today and ensure reliable, high-temperature connections in your electronic assemblies.
Frequently Asked Questions
Where can I buy SAMTEC SSW11302SDRA?
You can click on the BUY or RFQ button to purchase SSW11302SDRA from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW11302SDRA?
You can download the SSW11302SDRA datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW11302SDRA?
SAMTEC
