TDK Corporation SPM4012TR47MLR Power Inductor

The SPM-LR series 4012 type from TDK are high-quality, magnetic shielded wire-wound inductors designed for power circuit applications utilizing a metallic magnetic core. These low-profile components feature inductance values ranging from 0.47 µH to 4.7 µH and have a low DC resistance (DCR) from 17.6 mΩ to 196.7 mΩ. They can handle Isat currents from 3.3A to 8.5A and maintain consistent inductance performance at high temperatures, with minimal variance and good DC superimposition characteristics. These inductors are suitable for applications requiring large current capacity, low resistance, and compact size, with dimensions of 4.4mm x 4.1mm x 1.2mm. They are compatible with reflow iron soldering and operate effectively over temperatures from -40°C to +125°C, offering an inductance tolerance of ±20%.

View SPM4012TR47MLRDatasheet [pdf]

Buy the Buy TDK Power Inductors Part Number SPM4012TR47MLR Online

Get the TDK SPM4012-LR series power inductors now available online. These compact, reliable inductors feature metallic magnetic cores, low DCR, and a wide temperature range from -40°C to +125°C. Perfect for power supplies, VRMs, and electronic devices requiring high current capacity, they provide excellent inductance stability and low noise. Designed for surface-mount reflow soldering, these inductors ensure efficient energy storage and filtering in demanding power circuit applications. Buy now to improve your device's power management performance.

Order your TDK Series SPM4012TR47MLR magnetic shielded power inductor today and enhance your power circuit reliability with low resistance and high current capacity.
