TDK Corporation SPM6530TR25M230 Magnetic Shield Inductor
The SPM6530 series is a magnetic shield wound inductor designed for power circuits, utilizing metallic magnetic material to achieve high current, low RDC, and a compact design. It offers stable inductance across high temperatures, good DC superimposition, and reduced hum noise compared to ferrite inductors. Suitable for PCs, HDDs, servers, VRMs, and power modules, it features an integrated molded coil structure, operating temperatures from -40°C to +125°C, and various inductance values with rated currents up to 28.5A. Ideal for reliable, efficient power management in electronic devices.
TDK Corporation SPM6530TR25M230 Magnetic Shield Inductor Specifications:
- Inductance: 0.25 to 68 μH with +20% tolerance
- DC Resistance: 2.10 to 48.4 mΩ depending on model
- Rated Current: 2.10 to 48.4 A (Isat)
- Operating Temperature Range: -40°C to +125°C
- Dimensions: L 22.4 mm max, W 16.4 mm +0.2/-0 mm, H 3 mm
- Material: Metallic magnetic material with integrated molded coil
- Frequency Range: 100 kHz
- Packaging: 1000 pcs/reel, suitable for automated assembly
- Reflow Temperature: up to 260°C
- Self-heating: Included in temperature range
- Magnetic shield type: reduces hum noise
- Application: Power supply modules, VRMs, PCs, HDDs, servers
- Compliance: RoHS compliant
Buy the Industrial Magnetic Inductor – Reliable Power Circuit Component for Industrial Applications
Purchase the SPM6530 magnetic shield inductor now to optimize power circuits in your electronic projects. With high current capacity, low resistance, and excellent thermal stability, this inductor ensures reliable performance in PCs, servers, and power modules. Its integrated molded coil reduces hum noise, and its compact design fits various applications. Order online today for fast delivery and enjoy high precision components built for lasting durability and optimal power efficiency in demanding electronic environments.
Get SPM6530 inductor today—designed for high current performance and long-lasting durability in power management applications.
Frequently Asked Questions
Where can I buy TDK Corporation SPM6530TR25M230?
You can click on the BUY or RFQ button to purchase SPM6530TR25M230 from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part SPM6530TR25M230?
You can download the SPM6530TR25M230 datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of SPM6530TR25M230?
TDK Corporation
